Operating instructions
Soldering iron station ZD-927
Item no. 1089316
Intended use
This soldering iron station is suitable for soldering and desoldering SMDs (surface mounted
devices) that require diverse power levels. The control dial is used to set the required power
level. The soldering tip reaches a temperature of approx. 450 °C.
For safety and approval purposes (CE), you must not rebuild and/or modify this product. If you
use the product for purposes other than those described above, the product may be damaged.
In addition, improper use can cause hazards such as short circuiting, fire, electric shock etc.
Read the instructions carefully and keep them. Make this product available to third parties only
together with its operating instructions.
This product complies with the statutory national and European requirements. All company
names and product names are trademarks of their respective owners. All rights reserved.
Delivery content
• Soldering iron station
• Soldering iron with tip and connection cable
• Operating instruction
Explanation of symbols
This symbol indicates a health hazard, e.g. electric shock.
The exclamation mark indicates specific risks associated with handling, function and
use.
Safety instructions
Read the operating instructions carefully and especially observe the safety
information. If you do not follow the safety instructions and information
on proper handling in this manual, we assume no liability for any resulting
personal injury or damage to property. Such cases will invalidate the warranty/
guarantee.
• The device is not a toy. Keep it out of the reach of children and pets.
• This device is not intended to be used by persons (including children) with
reduced physical, sensory or mental abilities or lack of experience and / or lack of
knowledge unless they are supervised by a person responsible for their safety or
have received instructions on how to use the device.
• Children should be supervised to ensure that they do not play with the device.
• Do not leave packaging material lying around carelessly. These may become
dangerous playing material for children.
• Protect the product from extreme temperatures, direct sunlight, strong jolts, high
humidity, moisture, flammable gases, vapours and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of operation and
protect it from any accidental use. Safe operation can no longer be guaranteed
if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even from a low height
can damage the product.
• Before plugging in the device, verify that the information on the product's rating
plate correspond with your household power supply.
• The device was constructed according to protection class II. Only a proper mains
socket (230 V/AC, 50 Hz) of the public supply net must be used as voltage source.
• The mains outlet must be located near to the device and be easily accessible.
• Never pull the mains plug from the socket by pulling at the cable. Always pull it
Version 11/14
from the mains socket using the intended grips.
• Unplug the device when it is not in use.
• For safety reasons, always unplug the device in case of a thunderstorm.
• Make sure that the mains cable is not squeezed, bent, damaged by sharp edges
or put under mechanical stress. Avoid excessive thermal stress on the mains
cable from extreme heat or cold. Do not modify the mains cable. Otherwise the
mains cable may be damaged. A damaged mains cable can cause a deadly
electric shock.
• Do not touch the mains cable if it is damaged. First, power down the respective
mains socket (e.g. via the respective circuit breaker) and then carefully pull the
mains plug from the mains socket. Never use the product if the mains cable is
damaged.
• To prevent risks, damaged power cables may only be replaced by the
manufacturer, a professional workshop appointed by the manufacturer, or a
similarly qualified person.
• Do not fasten any objects to the soldering iron station, never cover the soldering
iron station, fire hazard!
• Never plug in or unplug the mains plug when your hands are wet.
• Never pour any liquids over electrical devices or put objects filled with liquid
right next to the device. If liquid or an object enters the interior of the device
nevertheless, first power down the respective socket (e.g. switch off circuit
breaker) and then pull the mains plug from the mains socket. Do not operate the
product anymore afterwards, but take it to a specialist workshop.
• Never use the product immediately after it has been brought from a cold room into
a warm one. The condensation generated could destroy the product. The power
supply unit also involves danger to life by electric shock! Allow the device to reach
room temperature before connecting and using it. This may take several hours.
• The soldering tip becomes very hot. Do touch it.
• Always set down the hot soldering iron on a heat-resistant surface. Set down the
soldering iron and its tip using the provided metal stand.
• After use, allow the product to cool down to room temperature.
• It is intended for indoor use only. Do not use it outdoors. Contact with moisture,
e.g. in bathrooms, must be avoided under all circumstances.
• Never submerge the product in water or other liquids. Risk of electric shock!
• For installations in industrial facilities, follow the accident prevention regulations
for electrical systems and equipment of the government safety organization or the
corresponding authority for your country.
• Do not inhale any vapours. Vapours are harmful. Only work with a flue.
• Consult an expert when in doubt about operation, safety or connection of the
device.
• Maintenance, modifications and repairs are to be performed exclusively by an
expert or at a qualified shop.
• If you have questions which remain unanswered by these operating instructions,
contact our technical support service or other technical personnel.
