• Always comply with the accident prevention regulations for
electrical equipment when using the product in industrial
facilities.
• Make sure that the cable is not pinched, kinked or damaged by
sharp edges.
• Consult a technician if you are not sure how to use or connect
the product.
• Maintenance, modifications and repairs are to be performed
exclusively by an expert or at a qualified shop.
• If you have questions which remain unanswered by these
operating instructions, contact our technical support service or
other technical personnel.
Operation
Never connect the product to a PC or notebook.
The USB port to which the product is connected must supply an
output current of 1.6 A (1600 mA).
Use a USB power supply or power bank as a power source.
• Remove the protective cap from the soldering tip. To do this, do not turn
the protective cap.
• Connect the jack plug of the supplied cable to the jack on the bottom of
the handle.
• Connect the USB plug with a suitable USB power source.
• Touch the small metal semi-sphere on the handle. The red LED lights up.
The soldering tip heats up. After approximately 15 seconds, the product
is ready for soldering.
• When you release the small metal semi-sphere, the product automatically
switches to sleep mode after 25 seconds. The heating process is stopped.
• To completely turn off the product, disconnect the cable.
Replacing the soldering tip
• Disconnect the product from the power supply. Allow the soldering tip to
cool down completely.
• Loosen the nut at the bottom end of the soldering tip. Remove the nut.
• Carefully remove the soldering tip.
• Insert a new, identical soldering tip.
• Secure the soldering tip with the previously loosened nut.
Care and cleaning
• Always disconnect the product from the power supply before cleaning it.
Allow the soldering tip to cool down completely.
• The product does not contain any components that require maintenance.
Never attempt to open or disassemble it.
• Never use aggressive detergents, rubbing alcohol or other chemical
solutions, as these may damage the housing or cause the product to
malfunction.
• Do not immerse the product in water or other liquids.
• Do not use a file or sandpaper to clean the soldering tip. This may damage
the soldering tip.
• Clean the soldering tip with a damp sponge to remove flux and solder
residue.
Then dry the soldering tip thoroughly.
• Clean the device exterior only with a soft, dry cloth or brush.
Disposal
Electronic devices are recyclable waste and must not be placed in
household waste. Always dispose of the product according to the
relevant statutory regulations.
You thus fulfil your statutory obligations and contribute to the
protection of the environment.
Technical data
Operating voltage ................... 5 V/DC
Power consumption ................ 8 W
Soldering temperature ............ max. 400 °C
Cable length ........................... 1.35 m
Operating conditions ............... -6 to +46 °C, 10 – 90 % RH
Storage conditions .................. -20 to +60 °C, 10 – 70 % RH
Dimensions (L x Ø) ................. 170 x 19 mm
Weight .................................... 22 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method (e.g. photocopying, microfilming, or the
capture in electronic data processing systems) requires prior written approval from the editor. Reprinting, also
in part, is prohibited. This publication represent the technical status at the time of printing.
Copyright 2018 by Conrad Electronic SE.
*1553058_v3_0418_02_IPL_m_en
