- Seite 4 Do not use a Nickel Cadmium or Nickel Metal Hydride battery charger to charge LiPo batteries. Damage to the batteries and charger will likely occur resulting in a fire. Verwenden Sie keine Nickel-Cadmium-oder Nickel-Metall-Hydrid-Akku Ladegerät LiPo-Akkus aufladen. Schäden an den Batterien und Ladegerät wird wahrscheinlich auftreten, was zu einem Brand.
- Seite 5 Top View Parts Front Bumper Front Control Arm Front Shock Absorber Steering Rack Front Body Mount Spur/Pinion/Slipper Steering Servo (Under Cover) Brushless Motor Electronic Speed Control (ESC) Transmission Battery Tray Battery Door Adjustable Battery Clamp Realistic Fuel Cell Rear Shock Absorber Rear Swing Arm Rear Axle...
-
Seite 6: Getting-Started Checklist
Getting-Started Checklist The following checklist is a guide for getting you vehicle running for the first time. Read ‘Cautions’ in Manual. (Page 2) Familiarize yourself with vehicle and Even though the vehicle is new check its components. driveshaft setscrews and other screws to make sure they are tight from the factory. - Seite 7 Range-Checking Your Radio System The radio system should be checked before operating the vehicle to ensure it’s operating properly and has adequate range. 1. Turn on the transmitter first and then the vehicle. 2. Have a friend hold the vehicle while keeping hands and loose clothing away from moving parts. 3.
- Seite 8 Recommended motor: AX31047 Battery Tray Access and Setup 1.Remove clip to open battery access door AXA114 AXA114 2.Slide battery in to check height 3.Remove X4 M3x8mm AXA114 Screw 4.Drop battery clamp down to required battery height. Snug fit required AXA114 5.Reinstall X4 M3x8mm AXA114 Screws AXA114 AXA114...
- Seite 9 See instructions below BIND ST-TRIM TH-TRIM ST-D/R...
- Seite 10 AXIAL LIMITED WARRANTY Your Axial product is warranted to be free of defects in materials and workmanship when new in the factory sealed box. This warranty does not cover damages due to normal wear and tear, users' failure to perform routine maintenance, error of assembly or installation, modifications or addition of aftermarket parts or option parts.
- Seite 11 NOTES Rear Suspension Tuning Upper Link Adjustments AXA119 AXA119 AX31104 AX31104 •AX31104 Mounts can be installed on either side of the AX31103 Chassis Tub AX31119 AX31119 •Swapping the AX31104 mounts will AXA1052 AXA1052 provide a suspension more suited to low AXA119 AXA119 speed technical terrain.
- Seite 13 AX80018 AX80006 Servo Set AX80033 AX80018 10m Shock Parts Tree 1 Hardware Parts Tree AX80091 AX80034 EXO Bulkhead 10mm Shock Parts Tree 2 AX80071 AR60 OCP Straight Axle Adapter AX80070 AX80035 AR60 OCP Differential Cover 10mm Shock Caps Parts Tree AX80072 AX80069 AR60 OCP 4-Link Mount...
- Seite 14 AX80103 EXO Rear Light Bezel and Radiator Set AX80119 EXO RTR Links Parts Tree AX80106 EXO Steering Knuckle Carrier Set AX31110 Yeti™ Steering Knuckle Set AX31111 Yeti™ Shock Tower and Body Post Set AX31104 Yeti™ Chassis Components AX31113 Yeti™ Rear Sway Bar Mount Set AX80111 EXO Lower Front Control Arms Set...
- Seite 15 AX31122 Yeti™ Front Bumper Set AX31105 AX31067 Yeti™ Chassis Electronic Slipper Plate Components AX31107 2-Speed Hi/Lo Transmission Spur Gear Cover AX31118 2.2 Walker Evans Wheels IFD™ Wheels - Black AX31106 2-Speed Hi/Lo Transmission Motor Mount AX80002 AX31059 Diff Case -Small Slipper Plate AX31125 Yeti™...
- Seite 16 AX31102 Yeti™ Rear Cage Components AX31117 AX31116 Y-380 Cage Top, Rear and Tire Carrier Y-380 Cage Front and inserts AX31103 AX31112 AX31115 Yeti™ Molded Chassis Tub Yeti™ Front Bumper Set Y-380 Cage Sides (Left and Right)
- Seite 17 AX31083 Radio Box Seals AX31083 Radio Box Seals AX31130 AX31130 AX31131 AX30390 AX30390 AX31131 T-Case Gear Set Differential Gear Set T-Case Gear Set High Speed Transmission igh Speed Transmission Differential Gear Set Gear Set Gear Set AX30382 EXO Steering King Pin AX31131 AX31058 T-Case Gear Set...
- Seite 18 AX31148 AXA144 AXA1041 4.5x6.5mm Joint Pin M3x8mm M2.5 Nylon Locking Hex Nut AXA146 AXA1052 AXA1184 M3x12mm M3 Thin Nylon Locking Hex Nut O-Ring 7.5x1.5mm AXA0147 AXA1053 M3x16mm M3 Nylon Locking Hex Nut AXA1202 O-Ring 3.5x2mm AXA148 AXA1045 M3x18mm M4 Nylon Lock Nut AXA1162 AXA150 O-Ring 5x1mm...
- Seite 24 AX12021 816874011949 2.2 BFGoodrich Krawler T/A - R35 Compound AX31111 816874012502 Yeti™ Shock Tower and Body Post Set (2pcs) AX31112 816874012519 Yeti™ Front Bumper Set AX24206 816874010133 2.4GHz Radio System (2 Channel) (AX-3, AR-3) AX31113 816874012526 Yeti™ Rear Sway Bar Mount Set AX24260 816874011055 AE-3 Vanguard ESC...
-
Seite 25: Option Parts
816874010447 67-90mm Shock Set - 10mm Piston (2pcs) AXA1331 877493003555 Flanged Ball 3x5.8x7mm (6pcs) AX30092 877493007126 Axial 72-103mm Shock Set - 10mm Piston (2pcs) AXA1412 877493006037 0.5x6mm Spacer - Grey (6pcs) AX30110 877493007119 Axial Aluminum 13mm Aluminum Preload Collar (2pcs)
