Verwandte Anleitungen für Axial Wraith Spawn
Inhaltszusammenfassung für Axial Wraith Spawn
- Seite 1 COVER...
- Seite 4 Make sure charger is correct for battery type selected for use. Examples: Do NOT charge Lipo batteries with Nickel Metal Hydride charger. Do NOT charge Nickel Cadmium batteries Lipo charger. Stellen Sie sicher, Ladegerät ist korrekt für Batterietyp zur Verwendung ausgewählt. Beispiele: Laden Sie keine Lipo-Akkus mit Nickel-Metall-Hydrid-Ladegerät.
- Seite 5 Top View Parts Tactic TSX45 Servo Steering Rack C-Hub Steering Knuckle Receiver Box Spur/Pinion/Slipper Transmission (Under Cover) Motor 20T AE-5 Electronic Lower 4-link Bar Speed Control(ESC) Battery Straps ESC Plug Shock Absorber Battery Tray Full Tube Frame Composite Chassis...
-
Seite 6: Getting-Started Checklist
Getting-Started Checklist The following checklist is a guide for getting you vehicle running for the first time. Read ‘Cautions’ in Manual. (Page 2) Familiarize yourself with vehicle and Even though the vehicle is new check its components. driveshaft setscrews and other screws to make sure they are tight from the factory. - Seite 7 Range-Checking Your Radio System The radio system should be checked before operating the vehicle to ensure it’s operating properly and has adequate range. 1. Turn on the transmitter first and then the vehicle. 2. Have a friend hold the vehicle while keeping hands and loose clothing away from moving parts. 3.
- Seite 8 AE-5 Forward/Reverse ESC w/ Drag Brake NOTES...
- Seite 9 BIND ST-TRIM TH-TRIM ST-D/R (877) 64-AXIAL (877-642-9425) (877) 64-AXIAL (877-642-9425)
- Seite 10 AXIAL LIMITED WARRANTY Your Axial product is warranted to be free of defects in materials and workmanship when new in the factory sealed box. This warranty does not cover damages due to normal wear and tear, users' failure to perform routine maintenance, error of assembly or installation, modifications or addition of aftermarket parts or option parts. This warranty lasts as long as the original purchaser owns the product and is not transferable (verified by dated itemized sales receipt accompanied with product).
- Seite 11 AX80070 AX31114 Axial Diff Cover WB8 Driveshaft AX80078 Transmission Gear Cover AX80035 10mm Shock Caps Set AX80128 Wheel Hub Adapters AX80006 Servo Set AX80071 Straight Axle Adapter Rear AX80072 Offset Axle 4 link mount...
- Seite 12 AX80088 AX80087 AX80083 AX80131 Rock Buggy Main Frame Rock Buggy Main Frame Rock Buggy Links Set Motocross Helmet AX80077 Rock Buggy Front End 1 AX31179 Wraith Radio Box Mount AX80075 Wraith Tube Frame TOP AX80069 Offset Axle Housing...
- Seite 13 AX80074 Rock Buggy Main Frame AX80081 Optional ESC Mounts AX31178 2.2 Method Beadlock Wheel Face AX80082 Rock Buggy Battery Brace AX80079 Rock Buggy Skid Plate/Battery Tray AX80076 Rock Buggy Rear Brace Set AX80089 Rock Buggy Front End 2 AX80073 Offset Axle Steering Link...
- Seite 14 AX31027 4x11mm bushing AX80018 Hardware Parts Tree AX31027 Spurs 32DP 56T AX80033 10mm Shock Set 1 AX80062 XR10 C Hub Carrier Set AX80010 Gear Set AX80036 72-103mm Shock Body AX80034 10mm Shock Set 2 AX80051 Dig Transmission Case AX30419 Solid Axle Dogbone 7x69mm AX80061 Steering Knuckles Plastic Set AX30419...
- Seite 15 AX30394 Shaft 5x18 20T Drive Gear AX30385 Diff Gasket 16x25x0.5mm AX31083 Radio Box Seals AX30408 Input Shaft 5x29mm AX30723 Pinion 32DP 12T AXA1393 AX30491 AX30128 AX30777 E2.5 e-clip AX10 Scorpion Motor Plate Axial Spring 14X70mm-Super Soft (Red) 56x17mm Servo Plate...
- Seite 16 AXA1356 AXA1040 Silicone Shock Bushing 7.5x8mm M3 Thin Hex Nut AXA0414 M2.6x10mm AX31250 M4 Serrated Nylon Locking Nut (Black) AXA1041 M2.5 Nylon Lock Nut AXA464 AXA1280 M3x8mm M3x10mm Servo Flange Screw AXA1052 M3 Thin Nylon Locking Hex Nut AXA013 AXA465 AXA1053 M2x6mm M3x10mm...
- Seite 17 Body Assembly AXA422 AX80131 AXA422 AX80131 AXA434 AX31176 AXA422 AX31177 AXA422 AXA422 AXA422 AXA422 AXA422 AXA438 AXA438 AXA438 AXA438 AXA436 AXA438 AXA438 AXA438 AX80075 AXA438 AXA438 AXA438 AX80088 AXA438 AXA438 AX80074 AXA438 AX80076 AX80089 AXA437 AX80076 AX80082 AX80077 AXA438 AXA441 AXA438 AX80089 AXA438...
- Seite 18 AX30032 AXA180 AXA414 AX30031 AXA414 AXA414 AXA414 AX31179 AX31144 AX31083 AX24206 AX80081 AX31179 AX31083 AXA424 AX31083 AX31179 AXA413 AXA413 AX80078 AXA414 AX30491 AX31026 AX31068 AX31180 AX31027 AX31068 AX30127 AX31026 AX80078 AXA0414 AX30413 AXA0414 AXA1045 AXA0286 AX31028 AX80078 AX31148 AXA0414 AX31114 AX31114 AX31148 AX31148...
- Seite 19 AXA0413 AX30041 AX80035 AXA0413 AXA1356 AXA0413 AXA0413 AX30112 AX30041 AXA1041 AXA1069 AX80033 AXA1069 AX80079 AXA1070 AXA291 AX30155 AXA083 AX24003 AXA1070 AX30723 AXA083 AX80036 AXA089 AXA089 AXA0113 AX30162 AX80051 AX80051 AX80035 AXA0113 AXA089 AX30198 AXA116 AX30394 AXA1218 AXA1184 AXA116 AX80051 AX80035 AX80010 AXA1218 AX80051...
- Seite 20 AXA0439 AXA187 AX80018 AX80034 AXA118 AXA435 AX31250 AXA118 AX80018 AX80083 AXA435 AXA437 AX31028 AX30778 AX80018 AXA1221 AXA1052 AXA1052 AX80061 AXA091 AXA115 AX80083 AX80018 AXA1230 AXA464 AX30450 AXA433 AXA465 AX30368 AX80018 AX80083 AX80072 AX80062 AX80018 AX80034 AXA437 AX30450 AXA0439 AXA1053 AXA433 AX30419 AXA115 AXA0439...
- Seite 21 AXA1230 AX80070 AXA015 AX31250 AXA435 AX80070 AXA435 AXA433 AX80002 AXA015 AX31028 AX30500 AXA435 AX80071 AXA118 AXA435 AX80070 AX30385 AXA187 AXA1221 AXA464 AX80083 AX80018 AXA433 AX30392 AXA465 AX80018 AXA1052 AX80072 AXA1230 AX30776 AXA0439 AXA440 AXA015 AXA015 AXA118 AXA087 AXA015 AXA015 AXA1393 AX30163 AX80070 AXA180...
- Seite 22 M3x3mm Set Screw (Black) (10pcs) AX31176 Wraith Spawn Body - .040" (Clear) AXA186 M3x16mm Set Screw (Black) (10pcs) AX31177 Wraith Spawn Interior Set - .040" (Clear) AXA291 M4x4mm Set Screw (Black) (6pcs.) AX31178 2.2 Method Beadlock Wheels - IFD™ Wheels - Black(2pcs) AXA291 M4x4mm Set Screw (Black) (6pcs.)
-
Seite 23: Option Parts
AX30091 67-90mm Shock Set - 10mm Piston (2pcs) AX8092 Axial 2.2 Rockster Beadlocks (Chrome) AX30092 Axial 72-103mm Shock Set - 10mm Piston (2pcs) AX8095 Axial 2.2 Rockster Beadlocks (Black Chrome) AX30103 Icon 61-90mm Aluminum Shock Set - 7mm piston (2pcs) AX8097 2.2 8 Hole Beadlocks (Black)
