Important: Never connect a mono earphone with a
2-pole plug to the jack . The 2-pole plug will cause a
short-circuit and may thus damage the unit .
4) Connect the plug-in power supply unit to the
power supply jack (1) of the base station and
to a socket (230 V/ 50 Hz) .

6 Operation

Switch on the system by turning up the control
(10) . The power indicators (9, 12) light up .
Audio transmission
calling station ➾ base station:
Go close to the calling station (optimum
distance 10 to 20 cm) and talk . At the base
station, adjust the volume of the speaker or
headphones with the control (10) . The per-
son at the calling station can trigger a signal
sound by pressing the button CALL (13) .
CAUTION Never adjust the headphones
to a very high volume . Per-
manent high volumes may
damage your hearing!
Audio transmission
base station ➾ calling station:
To make an announcement, keep the TALK
button (11) pressed and talk into the goose-
neck microphone (6) . The announcement
is reproduced via the speaker of the calling
station . After the announcement, release the
button .
To switch off the system, turn the control (10)
counter-clockwise until it locks (position OFF) .
The system has a low power consumption even
when it is switched off; therefore, disconnect
the power supply unit from the mains when the
system is not used for a longer period of time .
All rights reserved by Vivaldi Srl
any means for any commercial use.
. No part of this instruction manual may be reproduced in any form or by
®

7 Specifications

Gooseneck microphone: � � electret microphone
Power supply: � � � � � � � � � � ⎓ 9 V/ 300 mA via
Ambient temperature: � � � � 0 – 40 °C
Dimensions
Base station: � � � � � � � � � � 115 × 65 × 170 mm
Calling station: � � � � � � � � ⌀ 85 mm × 35 mm
Cable length: � � � � � � � � � 3 m
Subject to technical modification .
cartridge, cardioid,
300 mm gooseneck
supplied plug-in
power supply unit
(230 V/ 50 Hz / 7 VA)
