RTI NEO ONE Bedienungsanleitung Seite 10

Manual: RTI NEO ONE
9 Zoom
10 Strobe
11 Rotation
pattern Coarse
12 Rotation
pattern Fine
13 Grating
Selection
3. Interlock (RJ45)
There is an ‚Interlock IN' interface on the rear side of the PSU. The Interlock signal is forwar-
ded to the RTI NEO ONE via a data cable (just like the DMX signal).
An interlock connector is provided with the PSU for testing purposes. Use an E-Stop for
your laser shows. If an Interlock / E-Stop is plugged in the PSU, the laser output of the con-
nected RTI NEO ONE devices gets enabled (if key switch is in ‚ON' position).
4. Key Switch
There is a key switch on the rear side of the PSU. Please insert the key into the key switch
and turn it to ‚Laser ON' position to enable laser output of all connected NEO ONE devices.
Turn the key to ‚Laser OFF' to switch off the devices. Please remove the key to avoid unau-
thorized access.
5. Display
It is possible to adjust settings directly at the device by means of the integrated display and
the data entry wheel below it:
page 10 / 48
51 - 60 2 dots horizontal
61 - 70 2 dots vertical
71 - 80 3 dots horizontal
81 - 90 3 dots vertical
91 - 100 Circle
101 - 110 4 quarter circle
111 - 120 Test picture
241 - 255 Blackout
0 - 255 Gobo size
0 Strobe off
1 - 127 Strobe speed
128 - 255 Grow effect
0 - 255 Rotation MSB
0 - 255 Rotation LSB
0 No grating
1 - 127 Grating 1
128 - 255 Grating 2
active, if value
of channel 8
between 11
and 110
Strobe effect
2Hz - 12Hz
256 points - 0
points
If available
