Display

The Wi2U router is equipped with three two-coloured LEDs.
The following LED codes are associated with the device:
Function State
Power
Generated voltage within admissible range
Device in sleep mode
Problem with power supply
WLAN WLAN not started
activity WLAN Error
WLAN access point powers up
WLAN available but no data transfer
WLAN data transfer
3G 3G not started
activity 3G Error
Establishing 3G connection
3G available but no data transfer
3G data transfer
Firmware WLAN and 3G illuminate alternate red
update when the firmware update is running.
After restart, normal LED code resumes.
Reset to
WLAN and 3G flash simultaneous red –
factory for a period of 10 seconds

settings

32
Power supply
WLAN activity
UMTS/3G activity
Colour / LED code
slow flashing
Off
slow flashing
flashing
Off
slow flashing
flashing
alternate flashing,
each with 1 Hz (for the
duration of the update)
simultaneous
flashing, each with 1 Hz
Settings
Select the Settings menu. You will be prompted for a password if the settings page is
protected. The default password is „admin". For security reasons, the default password
should be changed to an individual password.
3G / UMTS
Connection name
The settings for your SIM card are administered under a freely definable connection
name. By default, this is usually the name of your provider. The connection name can
be changed manually.
Access Point Name (APN)
The Wi2U tries to determine the access settings automatically based on your SIM card
and stores them in the SIM card profile. You can change the settings here manually.
Roaming
You can switch on data roaming by activating the check box. With data roaming swit-
ched off, the router will not establish a connection when you are located outside of your
home network. By default, roaming is deactivated.
PIN
The PIN is requested when you first insert the SIM card and generally must not be
changed. If needed, you can change or set the PIN of your SIM card using the PIN
dialog.
