Familiarise yourself with all local conditions,
e.g. water connections and shut-off device,
prior to installation.
Please read these directions for use through
carefully before installation and use. Keep all
safety instructions and directions for future use.

Installation

Installing the fitting
Shut off the main water supply to prevent water
leakage. Let the residual tap water drain off.
Install the fitting as shown in fig. A and B.
CAUTION! Do not bend the flexible hoses
and do not put them under tension. Otherwise
there is a danger of material damage.
Flushing the fitting
In order to remove any possible impurities, the
fitting has to be flushed before it is used for the
first time (fig. C):
Unscrew the mixing nozzle
head.
Open the main water supply and the spray head
and allow the water to run for two minutes.
Then screw the mixing nozzle and the spray
head back on.

Operation

Bringing into use
Note: If the fitting has not been used for a long
period flush the pipes through thoroughly in order
to avoid stagnation and build-up of residues.
Open the main water supply.
Lift the adjusting lever
right or left in order to regulate the speed or
temperature of the water flow.
Press the changeover switch
spray jet.
4 GB/IE
9
and the spray
12
and swing it to the
13
to set the
10
Press the changeover switch once more to set
to normal spray jet operation.
Check operation of the mixer. For this purpose
move the lever in all possible positions. Please
regularly check all connections to ensure that
they are tight.
Pull the spray head down slightly and then
forward out of the holder to have freedom of
movement of the spray head when in use.
Limiting the water temperature
The cartridge in this faucet has a temperature
19
limiting function. This function is not activated
before leaving the factory (neutral setting).
CAUTION! Do not change the setting of the
temperature limit until you have installed the
fitting.
Shut off the main water supply.
Remove the red / blue hot / cold label
moving the lever to the highest setting and
13
carefully push the label out from the inside with
a long flat object (see fig. D).
Release the lock screw
clockwise using the Hexagonal key
CAUTION! Do not take the screw out com-
pletely; just loosen it until the lever can be easily
taken off.
Take off the lever.
Loosen the cartridge cover ring
and remove the cartridge securing ring
using a pipe wrench.
Subsequently remove the adjusting ring
Please note: Make sure that the mobile part
of the cartridge is oriented horizontally. This
makes it easier to remove the adjusting ring.
Do not use a wrench. Do not release the car-
tridge nut and do not take off the cartridge.
Replace the dial in its original position in order
to reduce the hot water supply.
Place the dial as described in fig. E in order to
limit the hot water supply.
Once again place the dial in the neutral position
to end the hot water limitation.
by
15
by turning it counter-
14
(see fig. D).
20
by hand
16
17
.
18
