Wear ear and eye protection
Special safety instructions
•
Avoid too high pressure
•
Keep bystanders and pets away
•
Children and animals should be kept far away
from the area of operation of the machine.
•
If the compressor is no longer in use, always
take the plug out of the plug socket.
•
Always make sure that compressed-air hoses
are used for compressed air and which are
characterized by a maximum pressure
adjusted to that of the compressor. Do not try
to repair the hose if it is damaged.
Additional safety instructions
•
Preferably wear safety glasses.
•
Do not use the tool in a work area where
stairs, ladders or scaffolding are involved.
•
Use accessories with adequate speed rating.
•
Never aim the air flow at people or animals.
•
Be cautious when using compressed air.
•
Only use clean and dry compressed air as a
power source for the tool. Never use oxygen
or a combustible gas.
•
Do not exceed maximum operating pressure.
•
Keep the tool clean. Do not use any
aggressive or alcohol-based cleaner.
•
Never use gasoline or other flammable liquids
to clean the tool. Vapours in the tool will ignite
by a spark and cause the tool to explode.
•
Disconnect the tool from the air supply before
troubleshooting or servicing, or during non-
operation.
•
Only carry the tool at the grip and never with
the trigger actuated.
•
Never carry the tool by the air hose or pull the
air hose to move the tool.
3. MOUNTING ACCESSORIES
Connecting and removing the air hose
Fig. B
•
Wrap a piece of sealing tape around the
connecting piece (7) of the air hose.
•
Fit the connecting piece of the air hose into
the connection (3).
•
Check whether the air hose is connected
properly.
Mounting a socket
Fig. C & D
•
Fit a socket onto the accessory holder (4).
•
Firmly press the socket onto the accessory
holder.
Adjusting the impact force
Fig. E & F
•
Turn the adjusting knob (2) counterclockwise
to increase the impact force.
•
Turn the adjusting knob clockwise to reduce
the impact force.
1 - 190 Nm
2 - 220 Nm
3 - 260 Nm
4 - 310 Nm
Changing the direction of rotation
Fig. A
•
Push the forward/reverse switch (6) forward
for clockwise rotation.
•
Push the forward/reverse switch backward for
counterclockwise rotation.
•
Tighten the screw.
4. USE
Instructions for use
•
Check whether the trigger can move freely.
•
Make sure that the tool is lubricated before
connecting it to compressed air.
•
Check if the air hose is correctly fitted.
•
Set the air pressure to a value within the
allowable operating pressure.
•
Only keep your finger on the trigger at the
moment of starting the tool.
Switching on and off
•
To switch on the tool, press the trigger switch (1).
•
To switch off the tool, release the trigger
switch.
Tightening and loosening fasteners
Fig. A, C & D
•
Fit a required socket.
•
Select the direction of rotation.
•
Place the tool on the fastener.
•
Switch on the tool.
•
If necessary, adjust the impact force.
