Troubleshooting guide

The trimmer does
not start.
The cutter bar and
blades become hot.
Poor battery
operating time.
The battery does
not charge.
Disposal
This product should be disposed of in accordance with local regulations.
If you are unsure as how to proceed, contact your local council.

Specifications

Hedge trimmer
No-load speed 1700 min
Cutter bar length 510 mm
15 mm
Cutting capacity
Weight 2.9 kg with 1.5 Ah battery or 3.2 kg with 3.0 Ah battery
LpA: 71.7 dB(A), K = 3 dB(A)
Sound pressure
LwA: 85.6 dB(A), K = 3 dB(A)
3.415 m/s², K = 1.5 m/s²
Vibration value
Battery 18 V li-ion
Capacity 1.5 Ah
1 hour
Charging time
Battery charger
Power supply 230 V, 50/60 Hz
Output 18 V DC
Output current 2.5 A
• The battery is discharged.
• Make sure that you have fully depressed both the safety
lock and start switch completely.
• Lubricate the blades and sharpen them if necessary.
• The hedge trimmer runs sluggishly. Lubricate the cutter
bar and blades.
• The battery is not fully charged.
• The battery needs replacing.
• The battery is not correctly inserted into the charger.
• The battery or charger contacts are dirty.
• The battery needs replacing.
• The mains lead is not securely plugged into the wall socket.
• Check to see if there is power at the wall socket.
• The charger or its cable is damaged.
• The battery is defective and must be replaced.
