Connecting a ash to the Ares
Receiver hot shoe
1. Turn o the
receiver.
2. Slide the ash into the receiver's hot shoe
mount.
3. Lock the ash with the ash's locking mecha-
nism.
4. Turn on the
receiver.
5. Set the ash to Manual mode.
* It is not unusual for the ash to discharge once
after turning on the Phottix Ares.
ash and the Phottix Ares
ash and the Phottix Ares
En
Connecting a ash/strobe to the
Ares receiver by sync cable
1. Turn o the ash/strobe and the Phottix Ares
receiver.
2. Connect a cable to the receiver's 3.5 mm Sync
Port.
3. Connect the opposite end of the cable to a
ash or studio strobe (A 6.3 mm adapter is
included for studio strobes with larger ports).
4. Turn on the ash/strobe and the Phottix Ares
receiver. Set the ash/strobe to Manual mode.
* It is not unusual for the ash to discharge once
after turning on the Phottix Ares.
