Phottix Ares Flash Trigger Benutzerhandbuch Seite 3

Receiver
1. Status LED
2. Hot Shoe Connection
3. Power Switch
4. DC Power Port
5. Channel Numbers
6. Channel Adjustment Buttons
7. 3.5mm Output Port
8. Battery Cover
9. Battery Compartment
10. Locking Ring
11. Cold Shot / Tripod Lug
En
6
9
8
11
INSTRUCTION MANUAL
1
5
7
10
3
2
4
3
