B-Speech Tera Benutzerhandbuch

User Manual
Tera Car Kit User Manual
1
1
2
2
3
3
4
4
5
5
6
6
About Tera
This versatile Bluetooth Car Kit Tera is specially designed for in-
car use and enjoy the convenience of freedom of Bluetooth
communication. Advanced Built-In Mic. with D.S.P. solution for
Echo Cancellation & Noise Suppression.
Dual Profiles- Headset & Hands-Free modes.
About Bluetooth Technology?
Bluetooth wireless technology is set to revolutionize the perso-
nal connectivity by providing freedom from wired connections-
enabling links and connectivity between mobile computers,
mobile phones, portable handheld devices and other Bluetooth
enables devices within 10 meters. Utilizing global sound & digi-
tal data 2.4G ISM transmission, it makes global communication
in the way you've never dreamed of!
Getting to know your Tera
Getting Started
To use Tera, please follow these simple steps:
(a) Plug your car kit into the cigarette lighter hole. Meanwhile,
the LED flashes green every 3 seconds and car kit is under
standby mode.
IMPORTANT: An optional cigarette lighter adapting collar is
recommended for different sized lighter holes.
(b) To power off the Tera, press and hold the MFB
for 3 seconds until the green LED flashes off.
(c) Place your Tera and a Bluetooth-enabled mobile
handset no more than 1 meter apart for pairing.
Turning On/Off the Car Kit
Turning On:
Tera is under off mode:
Press and hold the MFB for 3 seconds until you hear a short
beep. The LED will flash green every 3 seconds.
Turning Off:
Tera is under standby mode:
Press and hold the MFB for 3 seconds until you hear a short
beep. The LED will flash off.
IMPORTANT: Press the MFB again each time you turn on the
Tera to reactive the paring so that the connection in between the
car kit and paired mobile handset is resumed. For pairing, plea-
se refer to procedures under "Pairing".
Pairing
Prior to using the Tera for the first time, you must pair it with a
Bluetooth-enabled mobile handset. The following steps descri-
bes pairing instruction for a typical Bluetooth-enabled mobile
handset.
(a) Plug the Tera into the cigarette lighter hole.
(b) Place the Tera and mobile handset no more than
1 meter apart.
(c) Ensure the Tera is OFF.
(d) Press and hold the MFB for 6 seconds until you hear a long
beep. The green LED flash on. It's now ready for pairing.
(e) Activate your mobile handset's Bluetooth function by refer
ring to your mobile handset user guide for details. Mean
while, the handset will search for accessible Bluetooth
devices.
(f) Select "Car Kit" from the list.
(g) Enter the pre-programmed passkey "9999" and press "OK"
to pair the Tera and the handset. When pairing
is completed, you may hear a long beep. The Tera LED will
flash green every 3 seconds and
under standby mode.
(h) Press "Return" to go back to your handset's main menu.
For certain mobile handset models, a headset icon will be
shown on the screen. You should now be able to make and
receive calls using your Tera.
IMPORTANT: If the pairing cannot be completed within 2 minu-
tes while the pairing mode is activated, the Tera LED will flash
off and car kit is under off mode. Please repeat step (c) to (h) to
pair the headset and mobile handset again.
DC Plug
Connection/Link between Car Kit and
Bulit-in Microphone
Mobile Handset:
After pairing is completed, Tera is always under standby mode.
Incoming call / Finish /
Before you place or answer a call, if the headset ICON is not
Pairing / Send
shown on phone screen, please follow the simple steps to acti-
vate the Bluetooth connection/link through your handset or car
LED kit until the headset ICON is on the screen.
(1) On Handset: Select "Car Kit" from the paired list on your
handset screen.
Volume Control
(2) On Car Kit: Short press MFB and select "Accept" on
handset screen to accept connection.
Speaker
IMPORTANT: Whenever Bluetooth connection/link is removed,
for example: power off on car kit/phones or out of 10 meter sen-
sing distance, please activate connection/link as suggested.
Disconnection between Headset and mobile
Handset:
You may connect your car kit with another Bluetooth enabled
handset. Please follow the simple steps to disconnect the car
kit with the pre-paired handset.
(a) Power off the Tera.
(b) Select "disconnecting" to remove connection from your
handset list.
Using the Car Kit
Once pairing is completed, you may access the following functi-
ons. Some of the below-mentioned function is only accessible
for handsets supported with Hands-Free Profile.
(a) Answering a Call:
To answer a call, wait for the Tera to ring, then short press the
MFB to accept the call or answer the call via your mobile hand-
set in the normal way. Mean while you can hear a short beep
from the speaker.
(b) Ending a Call:
Short press the MFB, to end your call or end the call via your
mobile handset in the normal way. Mean while you can hear a
short beep from the speaker.
(c) Reject a Call:
When you hear the ringing tone, press and hold the MFB for 3
seconds until you hear a short beep.
(d) Voice Dialing:
If your mobile handset is voice dialing enabled, under standby
mode, press the MFB and when you hear a beep, say the voice
tag.
IMPORTANT: Please make sure to record voice tag into the
mobile handset before using voice dialing function. This functi-
on is only applicable to mobile handset with Bluetooth Hands-
Free Profile. Functionality varies depending on the mobile
handset models you have. Please refer to your mobile handset
user guide for additional information.
(e) Last Number Re-Dialing:
Under standby mode, short press MFB twice for last number
redial.
(f) Adjusting the Volume:
During conversation in progress, tune the Volume switch until
you reach the desired volume level.
LED Indication
STATUS
Power On & Standby
Power Off
Dialing Out
Answering Calls
Pairing in Progress
Pairing Completed
MFB - MULTI FUNCTION BUTTON
PRESS
Power On/Off
Pairing
Answering Calls
Ending Calls
Call Reject
Voice Dialing
Last Number Redial
Care and Maintenance
(a) Do not expose the car kit to liquid, moisture or humidity, as it
is not waterproof.
(b) Do not use abrasive cleaning solvents to clean the
Tera.
(c) Do not place the car kit in high temperature, as it will result
UK
LED
Flash green every 3 seconds
Off
Flash green every 2 seconds
Flash green every 2 seconds
Constant on
Flash green every 3 seconds
PRESS TO MFB TIME
3 second 1 time
6 second 1 time
1 second 1 time
1 second 1 time
3 second 1 time
1 second 1 time
1 second 2 time
in an explosion.
(d) Do not expose the Tera to contact with sharp
objects as this will cause scratching and damage.
(e) Do not stick anything inside the car kit as this may damage
internal components.
(f) Do not attempt to disassemble the Tera, as it
does not contain serviceable components.
(g) If you do not use the Tera for long periods, be
sure to store it in a dry place, free from extreme temperatu
re, humidity and dust.
Safety Information:
(a) Check local laws regarding use of a mobile handset and car
kit while driving. If you use the Tera while diving,
ensure your attention and focus remains on your responsibi
lity of driving safety.
(b) Never allow children to play with the Tera. Small
parts may be a choking hazard.
(c) Observe all signs that require an electrical device or RF
radio product to be switched off in the designated areas.
These could include hospitals, blasting areas, and potentially
explosive atmospheres.
(d) Turn off your Tera prior to boarding an aircraft.
Do not use your car kit in an aircraft.
(e) Never mount or store your Tera over any air bag
deployment area serious injury may result when an air bag
deploys.
Trouble Shooting:
If you are unable to connect your car kit and mobile handset,
please try the following:
(a) Ensure your car kit is turned on and plugged into the
cigarette lighter hole.
(b) Ensure the Tera is paired with your mobile
handset.
(c) Ensure your mobile handset's Bluetooth feature is activated.
Please refer to your mobile handset user guide for specific
instruction.
(d) Ensure the Tera is within a maximum of 10
meters of your mobile handset(s) and there are no obstructi
ons, such as wall or other electronic devices in between as it
may cause shorter or interference transmission.
(e) If all the above steps do not resolve your problem, please
remove your Tera from the cigarette lighter hole
for a while.
The Bluetooth car kit Tera is compliant with and adopts the
Bluetooth Specification 1.2. However, interoperability between
the device and other Bluetooth-enable products is not guaran-
teed because it depends on compatibility. For more information
on the compatibility between the device with other Bluetooth-
enabled products, please check with the manufacturer/importer.
Product Specifications:
• D.S.P. version with echo cancellation and noise suppression
for real full duplex.
• Bluetooth Specifications: Version 1.2, Class 2, 10 Meters
• Bluetooth Profile Supported: Headset & Hands-Free Profiles
• Operating Frequency Band: 2.402 to 2.480GHz Spectrum
• Input Voltage: DC 12-24V
• Dimension/weigh: L 15.5cm x W 5.5cm x H 3.2cm; 45g.
