Gude Expert Power Control 1202 Anleitung Seite 88

Spezifikationen
Request Code
Starting Address
Quantity of coils
Response Code
Byte count
Coil Status
·
Read Discrete Inputs (0x02)
Liest den Status der DC Eingänge:
Request Code
Starting Address
Quantity of Inputs
Response Code
Byte count
Input Status
·
Write Single Coil (0x05)
Setzt den Status eines Ports (Relais):
Request Code
Output Address
Output Value
Response Code
Output Address
·
Write Multiple Coils (0x0F)
Setzt den Status mehrerer Ports (Relais):
Request Code
Starting Address
Quantity of Outputs
Byte count
Outputs Value
Response Code
Starting Address
Quantity of Outputs
Expert Power Control 1202/1292
1 Byte 0x01
2 Bytes 0x000 to 0x3ff
2 Bytes 1 to 0x400
1 Byte 0x01
1 Byte n
n Byte each Bit represents a state
1 Byte 0x02
2 Bytes 0x400 to 0x7ff
2 Bytes 1 to 0x400
1 Byte 0x02
1 Byte n
n Byte each Bit represents a state
1 Byte 0x05
2 Bytes 0x00 to 0x3ff
2 Bytes 0x0000 or 0xff00
1 Byte 0x05
2 Bytes n
1 Byte 0x0f
2 Bytes 0x00 to 0x3ff
2 Bytes 1 to 0x400
1 Byte n
n x 1 Byte each Bit represents a state
1 Byte 0x0f
2 Bytes 0x00 to 0x3ff
2 Bytes 1 to 0x400
