Gude Expert Power Control 1202 Anleitung Seite 68

Spezifikationen
epc1292TrapAddr
epc1292portNumber
epc1292PortIndex
epc1292PortName
epc1292PortState
epc1292PortSw itchCount
epc1292PortStartupMode
epc1292PortStartupDelay
epc1292PortRepow erTime
epc1292ActivePow erChan
epc1292Pow erIndex
epc1292ChanStatus
epc1292AbsEnergyActive
epc1292Pow erActive
epc1292Current
epc1292Voltage
epc1292Frequency
epc1292Pow erFactor
epc1292Pangle
epc1292Pow erApparent
epc1292Pow erReactive
epc1292AbsEnergyReactive
epc1292AbsEnergyActiveResetta-
ble
epc1292AbsEnergyReactiveRe-
settable
epc1292ResetTime
epc1292Forw EnergyActive
epc1292Forw EnergyReactive
epc1292Forw EnergyActiveReset-
table
Expert Power Control 1202/1292
A unique value, greater than zero, for each receiver slot.
.50.1.1.1.2.1.2.x
DNS name or IP address specifying one Trap receiver slot. A port can
optionally be specified: 'name:port' An empty string disables this slot.
.50.1.3.1.1.0
The number of Relay Ports
.50.1.3.1.2.1.1.x
A unique value, greater than zero, for each Relay Port.
.50.1.3.1.2.1.2.x
A textual string containing name of a Relay Port.
.50.1.3.1.2.1.3.x
current state of a Relay Port
.50.1.3.1.2.1.4.x
The total number of sw itch actions ocurred on a Relay Port. Does not
count sw itch commands w hich w ill not sw itch the ralay state, so just
real relay sw itches are displayed here.
.50.1.3.1.2.1.5.x
set Mode of startup sequence (off, on , remember last state)
.50.1.3.1.2.1.6.x
Delay in sec for startup action
.50.1.3.1.2.1.7.x
Delay in sec for repow er port after sw itching off
.50.1.5.1.1.0
Number of suppported Pow er Channels.
.50.1.5.1.2.1.1.x
Index of Pow er Channel entries
.50.1.5.1.2.1.2.x
0 = data not active, 1 = data valid
.50.1.5.1.2.1.3.x
Absolute Active Energy counter.
.50.1.5.1.2.1.4.x
Active Pow er
.50.1.5.1.2.1.5.x
Actual Curent on Pow er Channel.
.50.1.5.1.2.1.6.x
Actual Voltage on Pow er Channel
.50.1.5.1.2.1.7.x
Frequency of Pow er Channel
.50.1.5.1.2.1.8.x
Pow er Factor of Channel betw een -1.0 and 1.00
.50.1.5.1.2.1.9.x
Phase Angle betw een Voltage and L Line Current betw een -180.0 and
180.0
.50.1.5.1.2.1.10.x
L Line Mean Apparent Pow er
.50.1.5.1.2.1.11.x
L Line Mean Reactive Pow er
.50.1.5.1.2.1.12.x
Absolute Reactive Energy counter.
.50.1.5.1.2.1.13.x
Resettable Absolute Active Energy counter. Writing '0' resets all reset-
table counter.
.50.1.5.1.2.1.14.x
Resettable Absolute Reactive Energy counter.
.50.1.5.1.2.1.15.x
Time in seconds since last Energy Counter reset.
.50.1.5.1.2.1.16.x
Forw ard Active Energy counter.
.50.1.5.1.2.1.17.x
Forw ard Reactive Energy counter.
.50.1.5.1.2.1.18.x
Resettable Forw ard Active Energy counter.
OCTETS RW
Integer32 RO
Integer32 RO
OCTETS RW
INTEGER RW
Integer32 RO
INTEGER RW
Integer32 RW
Integer32 RW
Unsigned32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Integer32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Gauge32 RW
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
