Spezifikationen
snmp snmpv3 authalg set {NONE=0|MD5=1|
SHA1=2|SHA256=3|SHA384=4|SHA512=5}
snmp snmpv3 authalg show
snmp snmpv3 privalg set {NONE=0|DES=1|
3DES=2|AES128=3|AES192=4|AES256=5|
AES192*=6|AES256*=7}
snmp snmpv3 privalg show
snmp snmpv3 authpassw d set "{passw d}"
snmp snmpv3 privpassw d set "{passw d}"
snmp snmpv3 authpassw d hash set "{passw d}" sets SNMP v3 authentication hashed passw ord
snmp snmpv3 privpassw d hash set "{passw d}" sets SNMP v3 privacy hashed passw ord
snmp trap type set {NONE=0|V1=1|V2=2|V3=3}
snmp trap type show
snmp trap receiver {trap_num} set "{dns_name}"
snmp trap receiver {trap_num} show
syslog
syslog enabled set {OFF=0|ON=1}
syslog enabled show
syslog server set "{dns_name}"
syslog server show
system
system restart
system fabsettings
system bootloader
system flushdns
system uptime
system panel enabled set {OFF=0|ON=1}
system panel enabled show
system display enabled set {OFF=0|ON=1}
system display enabled show
vt100
vt100 echo set {OFF=0|ON=1}
vt100 echo show
vt100 numeric set {OFF=0|ON=1}
vt100 numeric show
vt100 reset
Hinweise
1. Befehl kann auf allen Ebenen ausgeführt werden
2. Die Ausgabe kann 2 Zeilen umfassen - die erste Zeile zeigt den aktuellen Zustand,
die zweite Zeile den Status nach einem Neustart
3. Die Ausgabe kann mehrere Zeilen umfassen
4. Bitte die Energie Sensor Tabelle konsultieren, um den richtigen Index zu finden
Energie Sensor Tabelle
Index Beschreibung
0 Forward Active Energy
1 Power Active
2 Voltage
3 Current
4 Frequency
5 Power Factor
Expert Power Control 1202/1292
sets SNMP v3 authentication
show SNMP v3 authentication algorithm
sets SNMP v3 privacy algorithm
show SNMP v3 privacy algorithm
sets SNMP v3 authentication passw ord
sets SNMP v3 privacy passw ord
sets type of SNMP traps
show SNMP trap type
sets address and port of SNMP trap receiver
{trap_num}
show address and port of SNMP trap receiver
{trap_num}
enters cmd group "syslog"
enables syslog msgs on/off
show if syslog enabled
sets address of syslog server
show s address of syslog server
enters cmd group "system"
restarts device
restore fab settings and restart device
enters bootloader mode
flush DNS cache
number of seconds the device is running
blocks panel buttons w hen not enabled
show s if panel buttons are enabled
dark display w hen not enabled
show s if display enabled
enters cmd group "vt100"
sets console echo state
show s console echo state
sets numeric mode
show s numeric mode state
resets terminal
Einheit
Wh
W
V
mA
0.01 hz
0.001
