shut-down).
During this time, the device LED flashes (like in teach
mode).
If the delay time is short, the flashing may not even
be noticeable.

12 Maintenance and cleaning

This product is maintenance-free. Repairs are
only to be done by trained professionals.
Devices HM-LC-Sw2-FM and HM-LC-Bl1-FM
have an internal fuse!
This fuse protects the device relay from
greater current load. If the device becomes
overloaded and the fuse is blown, it can be
replaced by a technician!
Disconnect the mains power before removing
the device (switch the circuit breaker off)!
Work on the 230V network is only permitted
by qualified electricians (in accordance with
VDE 0100).
Replace fuses with same type fuses only
(round delay fuse 5 A)!
48
13 Technical specifications
Supply voltage:
Standby consumption:
Radio frequency:
Typ. open area RF range:
Receiver category:
Protection type:
Protection class:
Housing:
Housing color:
Ambient temperature:
Dimensions:
Subject to technical changes.
HM-LC-Sw1-FM
Relay:
Switching capacity:
HM-LC-Sw2-FM
Relay:
Switching capacity:
230 V/50 Hz
0.5 W
868,3 MHz
200 m
SRD Class 2
IP20
II
ABS
Light gray
+5°C bis +35°C
53 x 53 x 30 mm
(H x W x D)
Normally open
16 A (resistive load)
2x normally open
5 A (Sum of both chan-
nels, resistive load)
