Setting up the faytech Touch software
can also use a (non-touch) display and a touch screen. In the example below,
the touch-screen is display "1", while the second display "2" is a normal monitor.
Both have the same resolution, but the touch screen is the primary monitor.
: When this function is disabled, the touch screen
Enable multiple-monitors
will be mapped to the primary monitor automatically. When this function is
enabled, you can double click on the monitor area in the monitor geometry
window to assign the monitor area where the touch screen will be mapped.
Double-tap on the desired monitor and answer the question in the pop-up
window with
.
Yes
After confirmation, your touches on the selected touch monitor will be
simulated as mouse clicks.
If the function "
The touch sensor is automatically connected to the main
" is activated, the program automatically puts the touch function on the
system
primary monitor, if only one monitor is connected.
The
settings allow you to set the size of the touch area on
Operation mode
your faytech touch-screen. E.g. if you select the "right screen", after a new
calibration only the right side of the monitor will work as a touch area. If you
select "other" and then click on the ->> button, you can set more modes or set
confirm
Is the touch- sensor attached to the monitor?
Yes
No
48
faytech Ltd. 2009
C
Setting up the faytech Touch software
up an individually touch-defined area.
tab: fine adjustment of the touch area
5. Edge Compensation
On this tab you can finely adjust the touch area. This is very useful when you
have problems touching at the edges of the touch screen. In the following image
you can see that the limits for all edges of the screen were corrected (to 110%).
E.g. if you have problems in the upper right area, just increase the upper and
right limit (
>> Bigger
). Confirm the change and try the new settings with the
Draw Test
. You can also use the X-axis and Y-axis displacement options to
compensate if your touch always seems to be off the same amount in the X
and/or Y directions.
The "
Support Edge Compensation
the corners of your faytech touch panels. This option should always be enabled.
tabs:
6. Hardware and About
The last two tabs are for information only - there are no options to select on
these tabs.
The
tab gives information about the design of the faytech touch
Hardware
display and the firmware used.
" option optimizes the touch detection in
49
