Charging Warnings

CAUTION: All instructions and warnings must be
followed exactly. Mishandling of Li-Po batteries can
result in a fi re, personal injury and/or property damage.
• NEVER LEAVE CHARGING BATTERIES UNATTENDED.
• NEVER CHARGE BATTERIES OVERNIGHT.
• By handling, charging or using the included Li-Po battery,
you assume all risks associated with lithium batteries.
• If at any time the battery begins to balloon or swell,
discontinue use immediately. If charging or discharging,
discontinue and disconnect. Continuing to use, charge or
discharge a battery that is ballooning or swelling can result
in fi re.
• Always store the battery at room temperature in a dry area
for best results.
• Always transport or temporarily store the battery in a
temperature range of 40–120º F (5–49° C).
• Do not store battery or model in a car or direct sunlight. If
stored in a hot car, the battery can be damaged or even
catch fi re.

Battery Charging

Your aircraft comes with a 1S 3.7V DC Li-Po
battery charger and 1S 3.7V 150mAh 45C Li-Po
battery. Refer to the charging warnings.
It is recommended to charge the battery pack
while you are inspecting the aircraft. The fl ight
battery will be required to confi rm proper aircraft
operation in future steps.
NOTICE: Charge only batteries that are cool to the touch
and are not damaged. Look at the battery to make
sure it is not damaged e.g., swollen, bent, broken or
punctured.
1. Insert the charger into a USB port. The charger only
uses power from the USB port, it will not connect to
your computer. USB power supplies, such as those
used to charge cellular phones, can also be used.
2. Slide the battery into the slot on the charger and press
it into the charge jack/connector located at the bottom
of the slot. The end cap of the battery is specifi cally de-
signed to allow the battery to fi t into the slot one way
(usually with the label on the battery facing outward) to
prevent reverse polarity connection, however, check for
proper alignment and polarity.
3. Always disconnect the fl ight battery from the charger
immediately upon completion of charging.
EN
• Always charge batteries away from fl ammable materials.
• Always inspect the battery before charging
• Always disconnect the battery after charging, and let the
charger cool between charges
• Always constantly monitor the temperature of the battery
pack while charging.
• ONLY USE A CHARGER SPECIFICALLY DESIGNED TO
CHARGE LI-PO BATTERIES. Failure to charge the battery
with a compatible charger may cause a fi re resulting in
personal injury and/or property damage.
• Never discharge Li-Po cells to below 3V under load.
• Never cover warning labels with hook and loop strips.
• Never charge batteries outside recommended levels.
• Never charge damaged batteries.
• Never attempt to dismantle or alter the charger.
• Never allow minors to charge battery packs.
• Never charge batteries in extremely hot or cold places
(recommended between 40–120° F or (5–49° C) or place
in direct sunlight.
SOLID RED LED
–Charging
USB Li-Po
LED OFF
Charger –Charge
Complete
DC Input:5.0V 350mA
EFLC1008
DC Output:4.2V 300mA
CAUTION: Only use chargers specifi cally
designed to charge the included Li-Po battery.
Failure to do so could result in fi re, causing injury or
property damage.
CAUTION: Never exceed the recommended
charge rate.
LED Indications
When you make the connection successfully, the LED on
the charger turns solid red, indicating charging has begun.
Charging a fully discharged (not over-discharged) 150mAh
battery takes approximately 30–40 minutes. The light goes
out when the charge is complete.
Solid Red: Charging
OFF: Max Charge
CAUTION: Once charging is complete,
immediately remove the battery. Never leave
a battery connected to the charger.
4
