Addressing - Futurelight SC-250 Bedienungsanleitung

Channel 4 - Rotating gobo-wheel
0 - 23
24 - 47
48 - 79
80 - 103
104 - 127
128 - 151
152 - 175
176 - 207
208 - 231
232 - 255
Channel 5 - Rotating gobo index, rotating gobo rotation
0 - 127
128 - 191
191 - 192
193 - 255
Channel 6 - Shutter, Strobe
0 - 31
1 - 63
64 - 95
96 - 127
128 - 139
140 - 159
160 - 175
176 - 191
192 - 223
224 - 255
The Control Board on the top side of the SC-250 allows you to assign the DMX fixture address, which is
defined as the first channel from which the SC-250 will respond to the controller.
If you set, for example, the address to channel 5, the SC-250 will use the channel 5 to 10 for control.
Please, be sure that you don't have any overlapping channels in order to control each SC-250 correctly and
independently from any other fixture on the DMX data link.
If two, three or more SC-250 are addressed similarly, they will work similarly.
For address setting follow this procedure:
1. Switch on the SC-250 and wait until the fixture reset has finished ("rES" is flashing at the display).
2. Browse through the menu by pressing the [
"001". Confirm by pressing [
3. Use the [ ] and [ ] keys to select the desired address.
4. Confirm by pressing [
Controlling:
After having addressed all SC-250, you may now start operating these via your lighting controller.
Note:
After switching on, the SC-250 will automatically detect whether DMX 512 data is received or not. If there is
no data received at the DMX-input, the display will start to flash "001" with actually set address.
This situation can occur if:
- the 3 PIN XLR plug (cable with DMX signal from controller) is not connected with the input of the SC-250
- the controller is switched off or defective, if the cable or connector is defective or the signal wires are swap
in the input connector.
Note:
Closed
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Gobo 5
Gobo 6
Gobo 7
Gobo 8
Gobo 9
Gobo indexing
Forwards gobo rotation from fast to slow
No rotation
Backwards gobo rotation from slow to fast
Shutter closed
Gradual adjustment of the dimmer intensity from 0 to 100 %
No function (Shutter open)
Strobe-effect from slow to fast (max. 8 flashes/second)
Reset
Shutter closed
Pulse-effect in sequences with increasing speed
Pulse-effect in sequences with decreasing speed
Random strobe-effect with increasing speed
No function (Shutter open)

Addressing

] and [
] key and "001" will start to flash frequently.
] .
26
] keys until the display shows current address
