Installation and
Operation

3.1 Connections

The Power switch must always be on
the "Off" position before plugging the
amp to a properly earthed mains sock-
et (170-265V AC). The colour code is:
Blue: Neutral
Brown: Live, single phase
Yellow-green: Protective Earth
The input signal fed to the amplifier can
be either balanced or un-balanced. The
drawing below describes both ways to
wire an XLR connector for the purpose.
Balanced Signal: Connect pin 1 to
Ground, pin 2 to Signal + (hot) and pin
3 to Signal - (cold).
Unbalanced Signal: Connect Pin 1 to
Ground, pin 2 to Signal and pin 3 to
Ground.
Important!: If a connection is done with
a un-balanced line and pin 3 on the
XLR is not connected to ground, a 6 dB
loss occurs in the line and only a quar-
ter of the amplifier power is produced.
The amplifiers provides, for each chan-
nel, a female XLR Connector (Signal
Input) paralleled to a male XLR to daisy
chain several amplifiers with the same
signal line (LINK).
Anschluss und
Inbetriebnahme
3.1 Anschlüsse
Bevor Sie diese Einheit an eine
SHUKO-Steckdose anschließen, schal-
ten Sie den Hautstromschalter aus. The
colour code is:
Blue: Neutral
Brown: Live, single phase
Yellow-green: Protective Earth
Das Eingangssignal kann entweder
symmetrisch oder unsymmetrisch sein.
Für den Anschluss siehe Zeichnung.
Symmetrisches Signal: Die Belegung
der XLR Pins ist wie folgt: 1-Masse, 2-
Positives Signal (hot), 3-Negatives
Signal (cold).
Asymetrisches Signal: Die Belegung
der XLR Pins ist wie folgt: 1-Masse, 2-
Signal, 3-Masse.
Balanced Wiring
1- Ground
2- Signal +
3- Signal -
ACHTUNG! Wenn Sie ein asymetris-
ches Signal anschließen und Pin 3 nicht
an Masse anschließen, erzeugt dies
einen Verlust von 6dB (1/4 der Leistung
der Endstufe) am Ausgangssignal.
Die Endstufe verfügt über eine parallele
XLR-Buchse für die
Zusammenschaltung mehrerer
Endstufen.
6
Installation et
mise en service
3.1 Branchement
Veillez à ce que l'interrupteur de mise
en service soit en position "Off" avant
de brancher l'appareil sur une prise sec-
teur avec mise à la terre (170-265V
AC). The colour code is:
Blue: Neutral
Brown: Live, single phase
Yellow-green: Protective Earth
L'appareil peut fonctionner avec des
signaux symétriques ou assymétriques.
La figure ci-dessous indique le câblage
des connecteurs XLR pour les deux
cas.
Câblage Symétrique: souder la broche
1 à la masse, la broche 2 au point
chaud (+), et la broche 3 au point froid
(-).
Câblage Assymétrique: souder les
broches 1 et 3 à la masse, et la broche
2 au signal.
Unbalanced Wiring
1- Ground
2- Signal
3- Ground
Important: Si on effectue le branche-
ment d'un signal asymetrique sur le
connecteur XLR sans relier la broche 3
à la masse, une perte de 6dB sera
constatée , ce qui se traduira par une
perte du 75% de la puissance de sortie.
Le amplificateurs est muni des connec-
teurs XLR mâle pour la mise en
parallèle de plusieurs amplificateurs
avec les mêmes signaux d'entrée.
