Quick installation guide IB-AC653
Mounting frame for 1x 2.5" HDD/SSD in 3.5" bay
1. Package contents
1x IB-AC653, 1x screw set, 1x manual
2. Key features
• Fits into a standard 3.5" drive bay
• Supports 1x 2.5" HDD/SSD
• Metal material helps to release the heat of the HDD/SSD
3. Installation
• Correctly put the 2.5" HDD/SSD on the bracket, and mount it with screws.
• Turn off the power to your computer and any other connected peripheral
devices.
• Unplug the power cord from the back of the computer.
• Remove your computer's cover.
• Put the panel in one free 3.5" bay and fix it with the screws.
• Connect the internal cables of the computer to the referring connectors
of the HDD/SSD.
• Replace the computer cover and reconnect the power cord.
