TECHNISCHE DATEN

Receiver

Änderungen vorbehalten.
Allgemein
Stromverbrauch (FR 965)..................................................210 W
Stromverbrauch (FR 975)..................................................255 W
Stromverbrauch in Bereitschaft........................................< 2 W
Abmessungen, b × h × t ..........................435 × 135 × 350 mm
Gewicht (FR 965)...............................................................8,6 kg
Gewicht (FR 975)...............................................................9,4 kg
Verstärkerteil (0,7 % THD, 6 Ω, 1 kHz)
Ausgangsleistung, Stereo Modus (FR 965) (DIN) .......2 × 60 W
Ausgangsleistung, Surround Modus (FR 965)
Front ......................................................................2 × 60 W
Center ..........................................................................60 W
Surround................................................................2 × 60 W
Ausgangsleistung, Stereo Modus (FR 975) (DIN) .....2 × 100 W
Ausgangsleistung, Surround Modus (FR 975)
Front ....................................................................2 × 100 W
Center ........................................................................100 W
Surround..............................................................2 × 100 W
Bass.................................................................±9 dB bei 100 Hz
Höhen ..............................................................±9 dB bei 10 kHz
Loudness ...+6 dB bei 100 Hz (-30 dB); +3 dB bei 10 kHz (-30 dB)
Klirrfaktor................................................0,05 % bei 1 kHz, 5 W
Frequenzgang ............................................20–20.000 Hz, ±1 dB
Signal-Rauschabstand ...................................................≥ 82 dB
Stereokanal Trennung (1 kHz) ........................................≥ 45 dB
Kreuzkopplung (1 kHz)...................................................≤ -65 dB
Eingänge
Lineare Eingänge ................................................250 mV/47 kΩ
6 CH ....................................................................250 mV/40 kΩ
Front AV (nur FR 975)..........................................250 mV/22 kΩ
Phono ......................................................................5 mV/47 kΩ
Digital koaxial ..........................................75 Ω entspr. IEC 958
Digital optisch..................................................................Toslink
Digitale Sampling-Rate
(nur FR 965)...........................................32 kHz, 44,1 kHz, 48 kHz
Digitale Sampling-Rate
(nur FR 975)..............................32 kHz, 44,1 kHz, 48 kHz, 96 kHz
Ausgänge
Stromanschlüsse (geschaltet) ........................total max. 100 W
Lineare Ausgänge.................................................250 mV/1 kΩ
Digital koaxial ..........................................75 Ω entspr. IEC 958
Digitalausgang, Sampling-Frequenzen
Analog ein...........................................................aus 48 kHz
Digital eingang 32 kHz .......................................aus 32 kHz
Digital eingang 44.1 kHz .................................aus 44,1 kHz
Digital eingang 48 kHz .......................................aus 48 kHz
Digital eingang 96 kHz (nur FR 975)...................aus 48 kHz
Subwoofer pre-out....................................................0,8 V/1 kΩ
Center pre-out...........................................................0,8 V/1 kΩ
Kopfhörer ........................................8–600 Ω (3 V e.m.f., 60 Ω)
Lautsprecher .....................................................................≥ 6 Ω
90
Radioteil
Frequenzbereich
FM..............................................................87,5–108,0 MHz
MW...............................................................531–1.602 kHz
LW....................................................................153–279 kHz
Sensitivität
Stereo FM ..................................................................41 dBf
Mono FM....................................................................15 dBf
Klirrfaktor
Stereo FM ...................................................................0,3 %
Mono FM...................................................................0,85 %
Frequenzgang .............................................63–12.500 Hz ±1 dB
Signal-Rauschabstand
Stereo FM....................................................................55 dB
Mono FM.....................................................................60 dB
Kanaltrennung ...................................................35 dB bei 1 kHz
