7. Technical Data

Factor
Shipping weight incl resin*
Max. recommended power (l/min.)
Height*
Inner Diameter
Dimension of base
QuickChange Resin Bags
Max. fill with loose resin
Max. permanent pressure (bar)
Max. water temp. (°C)
Min. water temp. (°C)
*
These values are based on the „DIxxT" variation, including resin bags, TDS-meter, excluding wheels
or cart. For variation „C" with cart please consider following values:
Size incl. wheels (WxDxH): 55 x 108 x 67 cm. Weight (cart): 12,30 kg.
WarnIngs: read Before using!
• Do not drink the water produced by this system. Water produced by the
HydroPower DI system is too pure and will rob the body of vital minerals and nutrients
if imbibed in quantity.
• Prior to opening vessel housings, turn off water and relieve pressure in hose.
Press the yellow FastLock Opening lever on top to get pressure out of the
housings.
• If you use the QuickChange resin bags (recommended), pay attention on correct
position (be sure to seat bags with zip-tie facing up and sewing in parallel to vessel
ledge.
• If you use loose resin, pay attention on correct filling and prevent overfilling.
• After a longer non-usage period, flash the filter thoroughly so that only fresh water is
in.

tIps:

• Clean highest windows first. Start at the top of each window and clean using vertical strokes with moderate speed.
• DI Systems eliminate spotting so when you are finished cleaning, let the surfaces air dry - no need to wipe.
(NOTE: First time cleaning with pure water may necessitate washing windows twice for maximum results.
14
Hydropower dI
Technical Data
www.ungerglobal.com/hydropower
DI12T DI24T
11 kg 20 kg
6 10
35 cm 59 cm
20 20
28 x 30cm 28 x 30cm
1
6,25 l 12,5 l
8
30 30
2
DI48T
35 kg
20
116 cm
20
28 x 30cm
2 4
25 l
8 8
30
2 2
