Hydropower dI
EcoFlo-Water Flow Optimizer
5. EcoFlo - Water Flow Optimizer
Depending on the pressure of the incoming water supply, using the HydroPower EcoFlo
insert allows you to restrict the water flow to an optimum level of between 120 – 150 L per
hour, which is ideal for regular glass cleaning. Optimising the water flow in this way allows
you to use less pure water, extending the lifetime and performance of a single resin refill in
the HydroPower DI Filters by at least 20%, without compromising the quality of your work.
• Automatically reduces the water flow – see table below for details.
• Fits any industry standard valves.
• Can be fitted, removed or replaced inside the water flow valve in seconds – simple.
• Compatible with all HydroPower DI Filters, regardless of size.
• note: By reducing the flow it will take longer to fill a pure water
vessel / storage tank when using EcoFlo.
To speed up the filling process you should
remove the EcoFlo insert from the valve.
HOW TO FIT THE ECOFLO:
1
4
pressure
Bar
Output*
with EcoFlo
6 180 L/hour
5 150 L/hour
4
120 L/hour
3 Do not use EcoFlo!
* Pure Water Output at the brush
with EcoFlo and with Pole
Hose, 25 m
2
5
!
ATTENTION:
EcoFlo must be inserted into the Incoming
Water Valve (Inlet) only, located at the
bottom of the filter.
Inserting EcoFlo into the Outgoing Water Valve
(Outlet) may result in a build up of pressure inside the
filter vessel, potentially causing damage to the unit.
Do not use the EcoFlo when then pressure of
the incoming water is below 3 Bar.
Order your free EcoFlo:
EU: www.ungerglobal.com/ecoflo
www.ungerglobal.com/hydropower
UK: www.ungerglobal.com/uk/free-ecoflo
Quality Tools for Smart Cleaning
3
6
O-Ring must
be positioned
AFTER the
EcoFlo!
