Item Qty. Part No. Description
1
1
206657
2
1
200628
3
2
226401
4
1
900217
5
1
904840
6
1
900136
7
1
202820
8
1
202822
9
1
203063
10
2
906206
11
1
201625
12
6
203218
13
1
203220
14
1
201568
15
2
205528
16
8
203100
17
4
201651
18
2
206303
19
1
200627
20
12
201219
21
1
22
1
206219
23
1
203124
24
2
203617
25
1
201257
26
1
27
1
201160
28
1
201159
NOTE: Hardware kit is designed for more than one style of basketball system.
Not all hardware will be used.
P/N 21185802
02/04
PARTS LIST - See Hardware Identifier
Tank, (Black)
Wheel Axle
Wheel, 4" (Black)
Top Pole Section
Middle Pole Section
Bottom Pole Section
Rod, 3/8 O.D. x 4-3/4 Long
Eyebolt, 3/8-16 x 2-1/2 Long
Nylon Insert Lock Nut, 3/8-16
Tank Strut
Bolt, Hex Head, 5/16-18 x 3-3/4 Long
Washer, Flat, 3/8 I.D.
Nylon Insert Lock Nut, 5/16-18
Anchor, T-Strap
Bolt, Hex Flange, 5/16-18 x 1 Long
Nut, Hex Flange, 5/16-18
Spacer .500 I.D. x .25 Long
Washer 1/4 Flat
Wheel Bracket
Clip, Net Holder
Rim
Cap, Pole Top 3"
Stake, Tie Down
Plug Cap
Label, Height Adjustment and Moving
Net
Pawl Lever
Ratchet
Item Qty. Part No. Description
29
2
900846
30
1
206305
31
4
203113
32
2
203038
33
2
201129
34
1
240017
35
1
206360
36
1
203493
37
1
201124
38
1
203470
39
5
206340
40
1
203795
41
1
201125
42
4
201642
43
5
206304
44
4
908002
45
1
203472
46
1
900033
47
1
203796
48
1
200318
49
1
203365
50
1
202587
6
Backboard Bracket
Clevis Pin 1/4 x 2-9/32 Large
Bolt, Hex Flange , 5/16-18 x 2 1/2 Long
Bolt, Carriage, 5/16-18 x 2-3/4 Long
Spacer .402 I.D. x.500 O.D. x 1.8 Long
Bolt, Hex 1/4-20 x 2-1/4 Long
Bolt, Hex 3/8-16 x 2.65 Long
Lock Nut 1/4-20
Lock Nut 3/8-16
Washer Flat, Slam Jam
Nut 1/2-13
Nut, Special, Slam Jam
Return Ratchet Spring
Spacer .530 I.D. x.63 O.D. x .5 Long
Bolt 1/2-13 x 6-5/16 Long
Elevator Tubes
Spring, Black, Slam Jam
Bracket Slam Jam
T-Bolt, 3/8-16 x 5" Large
Bracket, Reinforcement, Slam Jam
Rim Spacer, Plastic
Spacer, .530 I.D. x 1" Long
