Installation of extra extension units
1. Make sure the existing tiptel DECT Set 50 (base and extension unit) is powered
on.
2. Unplug any cords attached to the Base unit (these will be connected again
later).
3. Plug the extra Extension unit into a power outlet near the Base unit and switch
power on. This will activate a red light on the Extension unit.
4. Plug one end of the supplied phone line cord into the Base unit and the other
end into the extra Extension unit. A red light will be activated before changing
to green (switch has to be turned over to C = computer for modem, fax or set
top box). This can take up to a minute.
5. Once the light changes on the Extension unit, unplug the phone line cord
between the Base unit and the Extension unit.
6. If a phone will be used, turn over the switch to S = speech for phone and the
light changes to orange.
7. Replug the cords which you have unplugged.
Go to chapter "Extension unit installation" to finish the installation process.

Operation Modes

Light shows
Steady Green
Flashing Green
No Light
English
BASE STATION
This means
Base unit is ready
One or more Extension units
are in use
No power to Base unit
Suggested fix
None, normal operation
None, normal operation
Check that the Base unit is properly
connected to a power outlet and that
the power is on
