EXPERT CHARGER 3 DUO
Charger
NR. 50 060 6051
DUO CHARGING
FUNCTION!

PRODUCT DESCRIPTION

The EXPERT CHARGER 3 DUO has been developed to charge
LiPo R/C battery packs of 1 to 3 cells or
LiFe-battery packsof 1 to 3 cells or
NiCd/NiMH R/C battery packs of 4 to 8 cells.
There are 3 charging methods:
• Automatic fast charge with a charging current of 1A, 2A or
4A, with delta V control (for NiCd and NiMH).
• Slow charge of transmitter and receiver battery with a
charging current of 150mA (only for NiCd/NiMH).
• Automatic fast charge with pre-defined discharge of
NiCd/NiMH R/C battery packs to reduce the memory effect
and to maintain the power of the battery pack. It is
recommended to discharge the battery pack every ten
charging cycles.
This charger can be connected to the 230V 50Hz mains socket
OR to the 12V DC vehicle cigarette lighter socket.
You can use both charging sockets at same time!!!
FAST CHARGE with 1A, 2A or 4A charging
current
1.
Connect the charger to the 230V 50Hz mains socket OR to
the 12V DC cigarette lighter socket. The yellow LED "INPUT"
should light.
2. Select the "LiPo", LiFe or "NiCd/NiMH" slide switch according
to the battery cell type.
-LiPo for 1 to 3 cells Lithium Polymer battery
-LiFe for 1 to 3 cells Lithium iron battery
-NiCd/NiMH for 4 to 8 cells Nickel Cadmium or Nickel Metal
Hydrid battery.
3. Select the 1A, 2A or 4A slide switch according to the required
charging current:
Current
Capacity NiCd/NiMH
1A
500 to 800mAh
2A
900mAh to 1,3Ah
4A
>1.3Ah
Please pay attention to the maximum charging current
allowed by the battery manufacturer.
For LiPo batteries the values listed below are valid:
Voltage level 3.7V per cell
Maximum charge voltage 4.2V per cell
For LiFe: Voltage level 3.3V per cell
Maximum charge voltage 3.7V per cell
4. If it is charging 2-3 cells LiPo/LiFe battery pack, connect the
5. Connect the R/C battery pack with the right polarity to the
6. Make sure the red LED "FAST" lights.
7. When charging process completes, the corresponding red
8. After termination of the fast charging process the red LED
FAST CHARGING with pre-defined discharge
For NiCd or NiMH R/C packs with 6 and 7 cells. Only
with charging- OUTPUT 1
1. Proceed as described in "FAST CHARGE" step1 to 5.
2. Press the button "CHARGE/DISCHARGE". The pre-defined
3. During discharge the green LED "DISCHARGE" lights.
CHARGING OF TRANSMITTER AND
RECEIVER BATTERIES
1. Connect the charger to the 230V 50Hz mains socket OR to
Capacity LiPo
2. Connect the battery pack with the correct polarity to the 4mm
1000-2000mAh
2000-4000mAh
> 4000mAh
3. Check whether the corresponding red LED lights to make
4. To terminate charging remove the battery pack from the
Charging time (hours) = battery pack capacity (mAh) x 1.4
balancing socket of the batterypack to the built-in balancer of
the corresponding output of the charger.
4mm charging sockets „OUTPUT1" and „OUTPUT2" at the
front of the charger by using an adapter cable (Not included).
LED „FAST" flashes.
goes out. A NiCd or NiMH battery pack can be left attached
to the charger for several hours without any damage. To
terminate charging remove the battery pack from the charger.
discharge of the battery pack connected is now started. By
pressing the button a second time the charger can be
manually switched back to the charging process.
Attention: The discharging time depends on the charging
status and the capacity of the connected battery pack and
can take several hours.
the 12V DC vehicle cigarette lighter socket.
charging sockets
TRANSMITTER or RECEIVER
"TX/
charger by using an adaptor cable (not included).
sure the charging process has been started.
charger.
The slow charging time can be determined according to the
following formula:
Charging current ( mA )
Example: 1500mAhx 1.4 = 14 hours
150mA
RX" at the front of the
