Specifications
Max. Rated Power (20 Hz-20 KHz) .......................................................................................260 W per CH., into 4 Ω
................................................................................................................................................................. 170 W per CH., into 8 Ω
Max. Rated Bridged Power (20 Hz-20 Khz) ........................................................................................ 520 W into 8 Ω
Impuls-Power (10msec) .........................................................................................................650 W per CH. into 4 Ω
Ιnput Sensitivity for full power (260W/4 Ω)....................................................................................................... 1,07 V
Input Impedance (balanced)........................................................................................................................... 20KΩ
Input CMRR ......................................................................................................................................................... >90dB
Voltage Gain (intern selectable) .................................................................................................................30(29dB)
Frequency Response ................................................................................................... 20Hz-20KHz(+0,-0,1dB 260W)
Phase Response .............................................................................................................. 20Hz-20KHz(1W)+1/-6Grad
Signal to Noise Ratio (A weighted) ................................................................................................................ -110 dB
Crosstalk .............................................................................................................................................................. -80 dB
Load Impedance (Save with all types of load) .......................................................................................... 16,8,4 Ω
Slew-Rate (input filter bypassed)................................................................................................................ 40V/µsec
DC-Offset ..........................................................................................................................................................<20mV
IMD (60Hz/7KHz 4:1)S.M.P.T.E. ..........................................................................................................................<0,04%
THD (into 4Ω 1KHz).............................................................................................................................................<0,02%
THD (into 4Ω 20Hz-20KHz) ..................................................................................................................................<0,1%
Damping Factor (1KHz/8Ω)....................................................................................................................................200
Controls .............................................................................Two front panel attenuators/front panel power switch
........................................................................................... rear panel ground lift switch/rear panel mode switch
Input Connectors ....................................................................Balanced 3-pin male and female XLR connectors
Output-Connectors ................................................................................................................. 2*NEUTRIK SPEAKONS
Protection ....................................................................DC voltage, hight temperature, turn on/turn off transient
............................................................. suppression, short circuit, soft clipping, subsonic and ultrasonic filtering
Indicators ............................................................................................................ 2Clip/2Protect/2Aktive/Signal-LED
Cooling................................................................................................................................................................ passiv
Required AC Mains ........................................................................................................................230 VAC/50-60 Hz
Power Consumption (Pink Noise,peaks at clipping point) ...........................................................................540 VA
Power Supply ......................................................................................................585 VAToroidal power transformer
........................................................................................................................................ 30000µF filter capacitance
Dimensions(including handles).................................................................................. Front 3,5 in (483x88x350 mm)
Weight .................................................................................................................................................................. 12 kg
Seite 13 PAS audio professional Power Amplifier
