Ventilators
Type ComPact 1500

2. Technical Data

Typ
Air-handling capacity max.(m³/h)
Static Pressure (Pa)
Power (V/Hz)
Power input max. (A)
Motor output max. (kW)
Protection class (IP)
Height x Width x Length (mm)
Weight (kg)
Sound level dB(A)
Duct Length (m)
Duct Diameter (mm)
Specifications are subject to change without notice. Some values are approximate.
3. Capabilities of the Blower
The ComPact 1500 is ideal for general use, confined space, hazardous ventilation and deliver
the highest airflow in their class. The double-wall, polyethylene casing is light weight, corrosion
and chemical resistant and handles the bumps and falls on any jobsite.
4. Operating Instructions
General
Plug in to a standard outlet with the correct voltage and amperage for the unit. Set the switch at
ON. Check for proper operation before leaving the unit unattended. Do not move or carry the
TurboDryer when it is running.
CPC – Quick-Couple Reversible Canister (optional)
Detachable in seconds, the Quick-Couple Canister with attached duct (7,6 m) conveniently
reverses from discharge to suction, making use and storage easier while protecting duct from
rips and tears.
ComPact 1500
1392
287
240 / 50
1,2
0,27
44
355 x 305 x 330
7,3
72
-
-
ComPact 1500
with Quick-Couple Canister CPC
6
CPC Quick-Couple
reversible Canisterr
-
-
-
-
-
-
356 x 305 x 1050
18
-
7,6
200
EN
