Direct-Media / Direct-Studio

1. Introduction

The Direct-Media / Direct-Studio is a high quality powered
loudspeaker for a wide range of applications. It allows you to
set up a mobile or fixed sound system quick and easy. This
professional design is easy to use even if you are not familiar
with the intricacies of sound reinforcement. A clear control
layout and rugged case make the Direct-Media / Direct-Studio
a user-friendly tool for every sound system application.

2. Safety

2.1 Precautions

1. This device has been manufactured and testet in
accordance with the German VDE safety guidelines for
electronic equipment. It has left the factory in perfectly safe
condition. In order to maintain safety and avoid risks of
damage or injury, take the usual precautions and follow all
safety instructions in the manual.
This device conforms to the German Class 1 safety
2. standards. When properly installed, all exposed metal parts
are permanently connected to safety ground. For safety
reasons, connect the equipment to a standard three-pin
outlet with protective ground only. Never open the safety
ground connection.
3. This device conforms to the EMC legislation currently in
force as certified by the CE mark on the device.
4. This device contains no user serviceable parts. To reduce
the risk of fire or electric shock, do not open the device
and refer servicing to qualified personnel.

2.1 Potential Risks

If the equipment
•
is visibly damaged;
•
contains loose parts;
•
does not operate correctly;
•
has been stored under adverse conditions (e.g., outdoors or
in a damp room) for extended periods of time; or
•
was exposed to high transportation stress (e.g., due to
inadequate packaging),
operating the equipment may be unsafe. Switch power to the
equipment off and mark the equipment.
Make sure the equipment cannot be connected to power or
switched on unintentionally by third persons.
8

3. Unpacking

Your Direct-Media / Direct-Studio comprises the following
components:
1. Aktivbox Direct-Media / Direct-Studio
2. IEC-Cable
Optional wireless microphone systems for Direct-Media:
1. Wireless receiver (will be installed in Direct-Media)
2. Handheld transmitter with microphone element, or
bodypack transmitter with lavalier or headset mivrophone
Please check that the package contains all components of the
system you ordered. If anything is missing, please contact your
Fohhn dealer immediately.

4. Description

4.1 General

Direct-Media
The Direct-Media is a powered loudspeaker. A built-in mixer
with 2-band equalizer lets you connect a CD player or similar
audio source, one wired microphone, and the optional supplied
wireless microphone for simultaneous operation.
The Direct-Media is also available with a pre-installed wireless
receiver that provides highly reliable and excellent audio
quality. A handheld or bodypack transmitter of your choice
(optional) makes the Direct-Media a self-contained sound
system for use with harwire or wireless microphones.
Direct-Studio
The Direct-Studio is a powered loudspeaker. A built-in mixer
with 2-band equalizer lets you connect two audio sources for
simultaneous operation.
The Direct-Studio is a magnetic shield loudspeakerbox for using
near a PC-Monitor.

4.2 Optional Accessories

Direct-Media / Direct-Studio
• Padded carrying bag for Direct-Media / Direct-Studio
• SHM1 stand adapter for Direct-Media / Direct-Studio
• Loudspeakerstand
• Microphone stand with boom
• Carrying bag for two stands
• Carrying bag for two stands and two SHM1 stand adapters
