8. Specifications

Modell
Amplifier power (rms/ peak)
EQ
Drivers
Enclosure
Maximal sound pressure level
Audio frquency response
Projection angle (HxV)
Mixer Inputs
Phantompower
Output
Connectors
Processor functions
Dimensions (W x H x D)
Weight
We reserve the right to alter the specifications without notice.
9. Wiring and Cabling
Balanced
From balanced high level output
2
XLR Female
3
1
T
T R S S
R
Unbalanced
From unbalanced high level output
2
XLR Female
3
1
Connect together inside the connector
T
T S S
Connect together inside the connector
T
T S S
Direct-Media
100 W
bass / treble
8" and annular
bass reflex
Multiplex, enamelded black
Plastic feet
36mm socket for stand
Impact resistant metal grille
Acoustic foam
M8 threads for SHM1 stand adapter
carrying handle
120 dB
80 Hz - 20 kHz (-6dB)
80° x80°
1 x wired mic 1 kOhm, sym.
1 x line Klinke 10 kOhm
2 x line Cinch 10 kOhm
12 Volts
1 x Line 0dB / 200 Ohm
for mix out
or stacking
Microphone:
1 x 3-pol XLR (F)
Line:
1 x jack 6,3mm
RCA jacks
(stereo summed to mono)
Limiter + Autosubsonic filter
240 x 340 x 230 mm
7,5 kg
To input
Direct-Media/ Direct-Studio
XLR Male
XLR Male
To input
Direct-Media/ Direct-Studio
T
S
XLR Male
T
S
Direct-Studio
100W
bass / treble
6" and dome tweeter
2 way
Multiplex, enamelded black
Plastic feet
magnetic shield
Impact resistant metal grille
Acoustic foam
M8 threads for SHM1 stand adapter
112 dB
48 Hz - 20 kHz (-6dB)
80°x80°
1 x Line 3-pin XLR
1 x Line jack 10 kOhm
2 x Line 10 kOhm
-
1 x Line 0dB / 200 Ohm
for mix out
or stacking
Line 1:
3-pin XLR (F)
Line 2:
jack 6,3mm
RCA jacks
(stereo summed to mono)
Limiter + Autosubsonic filter
240 x 340 x 230 mm
8 kg
2
3
1
2
3
1
S T
2
3
1
S T
