1.4 Equipment features

▪ Appealing graphic user interface with
numerous display modes, e. g. num-
ber of performance data, selecting
digital or analogue display, etc.
▪ Reads important engine parameters,
error messages and performance
parameters in seconds
▪ "Plug and Play" - Bluetooth inter-
face for smartphone and tablet for
ease of use
▪ Easily read and reset error codes
with the extensive DTC error code
database
▪ Displays freeze-frame and live per-
formance data, e.g. on-board volt-
age, actual speed, oil temperature,
oil pressure, etc.
▪ Extensive DTC error code database
▪ 16-pin diagnostic plug with future-
proof analysis chip
▪ Three LEDs for visual monitoring of
®
the Bluetooth connection status
▪ Free app available from the Play
Store. PC Software included on CD
▪ PC system requirements:
Windows XP, Vista or Windows 7
▪ App system requirements:
Android™ Version 2.3.3 or later
▪ Menu languages: German and English
1.5 Basic information on the Blue-
tooth OBD-II-Car Controller
On-board diagnostic systems (OBD)-II:
The acronym OBD-II stands for 2nd
generation On-board diagnostic
system. It can be used in EU vehicles
with spark ignition engines year of
manufacture 2000 and later and for EU
vehicles with diesel engine year of
manufacture 2003 and later.
22
80290_OBDII_Bluetooth_Manual_15_05_2013_Bocklet_print
Mittwoch, 15. Mai 2013 11:04:54
The vehicle's OBD-II system is used to
monitor the emission control system
and key electronics and engine data,
and checks certain vehicle compo-
nents and conditions. When a problem
is recognised the OBD-II system will
alert the driver via malfunction
indicator light (MIL) on the instrument
panel, which typically means the
engine should be checked or main-
®
tained as soon as possible.
The Bluetooth OBD-II Car Controller
allows for DTC error codes DTC =
Diagnostic Trouble Codes) to be read
and displayed, or, if needed, be
deleted. These error messages are
transmitted from the vehicle's memory
to the Bluetooth OBD-II Car Controller.
The various diagnostic trouble codes
consist of a five-digit alphanumeric
code and identify a specific vehicle
fault. The first character of the code is
a letter indicating the vehicle assembly
affected. The other four characters are
numbers and indicate the component
which triggered the error message (e.g.
P0202).
Using the Bluetooth OBD-II Car
Controller and / or the included
CD you can then assign this error code
to the respective error description.
