4. Technical data

Note:
The enclosed manual from Briggs & Stratton pro-
vides detailed technical data on the engine!
Engine type: ...... One-cylinder four-stroke engine
Power: ............... 12.8 kW (17.4 hp) at 2800 min
Fuel: .......................................................... Petrol
Cutting height adjustment: .. Central, (30-90 mm)
Cutting width: ...................................... 1,020 mm
Blade length: .......................................... 518 mm
Weight: ......................................................220 kg
Tire size, front: ....................................15 x 6.00-6
Tire size, rear: ....................................18 x 8.50-8
Air pressure of tires, front: ....................... 1.0 bar
Air pressure of tires, rear: ........................ 0.8 bar
Max. velocity, forward: ............. Infi nite 0 - 8.8 kph
Max. velocity, reverse: ................ Infi nite 0 - 5 kph
Towing capacity: ........................................300 kg
Vertical load: ...............................................75 kg
Battery: ............................................. 12 V 18 Ah
Sound and vibration
L sound pressure level .................... 86.9 dB(A)
pA
K uncertainty ............................................. 3 dB
pA
L sound power level ........................ 100 dB(A)
WA
K uncertainty ............................................. 3 dB
WA
Wear ear-muff s.
The impact of noise can cause damage to hea-
ring.
Total vibration values (vector sum of three direc-
tions) determined in accordance with EN 836.
Vibration emission value ah = 10.97 m/s
K uncertainty = 1.5 m/s
Anl_GE_TM_102_BS_SPK7.indb 25 Anl_GE_TM_102_BS_SPK7.indb 25
GB
-1
2
2
- 25 -

5. Before starting the equipment

Assembling the components
Some parts of the mower come disassembled.
The work of assembly should be carried out by 2
people. For quick and easy assembly, read and
follow the instructions below.
Important. You will need the following additional
tools (not supplied) for assembly, and also for
maintenance work:
•
A flat oil drip tray (for changing the oil)
•
A 1 liter measuring jug (oil/petrol resistant)
•
A petrol can
•
A funnel (suitable for the tank's petrol filler
neck)
•
Household wipes (to wipe up oil/petrol resi-
due; dispose of these at a filling station)
•
A petrol suction pump (plastic, available from
DIY stores)
•
An oil can with hand pump (available from
DIY stores)
Fitting the steering wheel (Fig. 9 - 11)
Place the machine on a straight and level surface.
Align the wheels straight ahead and fi t the stee-
ring wheel (Item 5) as shown.
Inserting and removing the battery
(Fig. 14-15)
Important. Use the mower only with a mainte-
nance-free 12V battery.
Place the battery (Item 37) on the base. First con-
nect the red cable "+" and then the black cable "-".
Secure the battery with the tensioning spring (Fig.
15). Remove it in reverse order.
Important. Do not disconnect the battery from
the electrical system during operation as this may
destroy the charge electronics.
Charging the battery from the electrical sys-
tem
The battery is charged by the generator via the
electrical system during operation.
Charging the battery with the charger
If the battery has lost its charge, it can be charged
up with a charger (not included in delivery) via the
household mains system. Disconnect the battery
from the electrical system as described in the
section: "Inserting and removing the battery". We
recommend that you use an Einhell charger.
