Description Of The Product; Technical Specifications - Thomson Rt240 Bedienungsanleitung

PORTABLE RADIO
EN
RT240
3
1 2 4
5 6 8
10
11
7 9

DESCRIPTION OF THE PRODUCT

TECHNICAL SPECIFICATIONS

1 Speaker • Power supply: 230V ~ 50Hz or 4 batteries LR14 (C) 1,5V (not
supplied)
2 Frequency selector • Frequency ranges
3 Power indicator and frequency indicator
4 OFF/ON/Volume
Note: Unit design and specifications are subject to change without
5 Handle
notice. The manufacturer reserves the right to make the necessary
improvements.
6 Telescopic antenna
7 Battery compartment
8 Grommet notch
9 Mains power supply cable
10 FM/MW/SW1/SW2 band selector
11 Auxiliary audio source input
USE
POWER SUPPLY
Mains power supply
FM: 88- 108 MHz • Remove the battery compartment cover.
MW: 540 - 1600 kHz • Plug the power cord into a mains socket. If the equipment is
SW1: 6.0 - 12 MHz powered by the cable, it is best to remove the batteries.
SW2: 12 - 18 MHz • Put the cover back in place.
Battery power supply
• Remove the battery compartment cover.
• Insert 4 LR14 1.5V batteries, ensuring that the indicated polarity
is followed.
• Put the cover back in place.
USING THE RADIO
• Turn the OFF/ON/VOLUME (4) button clockwise to switch on the
radio.
• Slide the band selector to FM, MW, SW1 or SW2 to select the
frequency range.
• Select the desired radio station by turning the TUNING (2) button.
• Adjust the volume by turning the OFF/ON/VOLUME (4) button.
• Turn the OFF/ON/VOLUME (4) button anti-clockwise to switch
off the radio.
To improve radio reception:
• In FM/SW1/SW2 mode, extend the telescopic aerial. Adjust its
position, length and angle to get the best reception quality.
• In MW mode, turn the whole radio to orientate the internal aerial
and get the best possible reception.
