Technical Specifications - AEG BSS 4820 Bedienungsanleitung

USB port (14)
This device has been developed according to the current
level of technology in the USB sector. However, the large
variety of different USB storage media of all kinds being
offered today makes it impossible for us to guarantee full
compatibility with all USB storage media. Because of this, in
rare cases there may be problems with playback from USB
storage media. This is not a malfunction of the device.
1. Press the SOURCE button (7) until the indicator lamp (2)
lights green.
2. Connect a USB storage medium directly. Then the play-
back starts.
Refer to the section "Description of the USB / Bluetooth
Operation Buttons" for operation.
NOTE:
• Always connect a USB storage medium directly to the
USB port to prevent problems.
• This USB port cannot be used to charge external
devices.
CAUTION:
Before you remove the USB storage medium, use the
SOURCE button to switch the unit to a different mode.
Description of the USB / Bluetooth
Operation Buttons
PAIR/ / (9)
• Press the button briefly to interrupt the playback. Pressing
the button again continues the playback from the same
position.
NOTE: Bluetooth music playback
Your playback device must support this function. De-
pending on the device, it may be necessary to start the
music app in advance on your playback device.
• Keep the button pressed to separate an existing Blue-
tooth connection or to activate the pairing mode manu-
ally.
• Press this button to accept or end an incoming call.
(5)
Press once = (Only in Bluetooth mode) Starts the
current title again from the beginning.
Press twice = Jumps to the preceding title.
Press three times = Plays a preceding title, etc.
• (Only in USB mode) Keeping the button pressed starts a
music search. By doing so, the sound is muted.
(5)
You can use this button to jump to the next or overnext title
etc.
• (Only in USB mode) Keeping the button pressed starts a
music search. By doing so, the sound is muted.
Cleaning
CAUTION:
Do not submerge the device in water.
• Before cleaning disconnect from mains power supply.
• Clean the device with a soft damp cloth without deter-
gents.
Troubleshooting
Fault Cause
Unit cannot be Unit crashes
operated. and "hangs".
No audio signal Speaker is not
via the Bluetooth paired to the
connection audio source.
Volume too
low
Speaker cannot Pairing does
be connected not work
Audio source
is switched off
Bluetooth is
switched off
at the audio
source.
Bluetooth
version is not
supported.

Technical Specifications

Model: .................................................................................BSS 4820
Battery operation: .................................................3.7 V, 1000 mAh
Power supply (AC adapter): ....................... DC 5 V, 2 A
Power Consumption:.............................................................12,5 W
Protection class: ...............................................................................III
Net weight: ............................................................approx. 0.895 kg
AC adapter
Protection class: ................................................................................II
Input: ........................................................ AC 100-240 V~ 50/60 Hz
Output: .............................................................................DC 5 V, 2 A
Polarity: .................................................................................
English
33
Solution
Disconnect from the
mains for around 5 sec-
onds. Then switch the unit
on again.
Check whether a connec-
tion exists. If necessary,
pair the speaker again to
the audio source.
Increase the volume on
the speaker
Increase the volume on
the audio source.
Check whether the audio
source supports the A2DP
protocol.
Switch on the audio
source
Switch on the Bluetooth
function in the audio
source.
Use a different playback
unit.
