1
2
3
5
6
1. Power
2. Source
3. Volume controls
4. Play/pause
5. Next/previous track
6. Bass control
7. Treble control
System Specifications:
• Total Power:
30W RMS
• Line-in Sensitivity:
500mV RMS
• Bass Control@100Hz:
+/- 8dB
• Treble Control@10kHz:
+/- 8dB
• SNR:
>80dB
Speaker Specifications
• Dual 2.75" ported drivers
• Dual 1.4" dome tweeters
• Downward firing subwoofer 3.5"
Unit Dimensions
• 13.75"w x 4.25"d x 5.90" h Speaker
8
4
3
7
9
2
AUX IN
18V 2.5A
10
11
1. Volume control knob
2. Dock connector
3. LED status indicators - source, volume, bass/treble
4. Play/pause control
5. Bass CONTROL
6. Treble control
7. Source control - iPod / iPhone, Bluetooth, Aux
8. Power button
9. iPod adapter insert holes
10. IR remote sensor
11. Built-in microphone
1. Line in jack
2. AC power jack
1
2
4
5
6
7
8
3
1
9
