Eng
Description of Parts
Main Unit
1. iPod docking station
2. iPod docking connector
3. POWER button ----- To turn the unit on and off ; select iPod or
AUX-IN mode
4. Power Status indicator: LED
5. Remote Control Sensor
6. VOL + / - button ----- Adjust volume level up or down
7. iPod PLAY / PAUSE button
8. / button ------- Skip tracks Forward / Backward ;
perform high-speed search
9. Speakers
10. Subwoofer
11. DC-in jack ----- For the connection of external DC power supply
12. iTunes mini USB connector
13. LINE IN jack ----- Auxiliary audio signal input
7
Description of Parts
Remote Control
1. Infrared Transmitter
2. STANDBY button
8
3. Up button
4. Down button
5. Left / button
5
6. Right / button
4
7. iPod PLAY / PAUSE button
10
8. MENU button
11
9. VOL + / - button -----
Adjust volume level up or down
14
10. TREBLE button ----
Adjust treble level
11. BASS button ----- Adjust bass level
12. ENTER button
13. MUTE button ----- Mute the volume
14. EQ button ----- Select preset EQ effect
15. Battery Compartment
Accessories
- iTunes USB cable x 1
- Auxiliary audio line in cable with 3.5mm stereo plugs ;
Length = 1 Meter x 1
- Auxiliary audio line in cable with 3.5mm stereo plugs ;
Length = 1.5 Meter x 1
- iPod docking station cover x 1
- AC / DC power adaptor x 1
8
Eng
1
2
3
7
6
9
13
12
15
