Installation

AC-DC Adaptor Connection
The unit can be powered by an external AC-DC Adaptor, required the output DC 24V
1000mA (included).
(1) Connect the adaptor's DC output plug to the DC-in jack of the unit.
(2) Firmly and securely plug the adaptor's AC plug into AC main outlet.
Remote Control
The remote control operates on one CR2032 battery (included).
To activate the remote control, remove the insulation tab inserted in the battery
compartment.
Warnings:
Batteries (battery pack or batteries installed) shall not be exposed to excessive heat
such as sunshine, fire or the like.
5

Description of Parts

Main Unit Top View
8 7 4 5 3 6
Front View
9 9
6
Eng
1
2
Rear View
12
10 13 11
