Screwdriver
•
Electric drill, 3 mm / 0.12" carbide drill bit
•
Mounting screws
•
Soldering gun
•
Power wire min. 8 mm² / 8AWG
• Ground wire min. 8 mm² / 8AWG
•
Speaker wire min. 2 x 2,5 mm² / 13AWG
• As a precaution it is advisable to disconnect the vehicle's battery before making connection to the +12
Volts supply wiring (see owner's manual of your car for further information).
•
Please use great caution drilling in your car. Your gas tank, brake lines or cables can be damaged by
puncturing with your drill bit – this could cause damage or failure of your cars operating systems.
• Never pass wires over sharp angles. It is recommended to buffer the power supply of the amplifier with an
additional capacitor (power cap) min. 1 F to guarantee a stable operation voltage.
Before beginning the installation, consider the following:
a) If you plan to expand your system by adding other components sometime in the future, ensure adequate
space is left, and cooling requirements are met.
b) If your radio is equipped with preamplifier outputs (RCA), it is advisable to use them.
a) Select a suitable location that is convenient for mounting, is accessible for wiring and has ample room for
air circulation and cooling.
b) Use the amplifier as a template to mark the mounting holes, remove the amplifier and drill 4 holes. Then
mount the amplifier with the mounting screws.
Chose a mounting position where all electric wires are protected from being damaged by sharp edges, heat or other
conditions. +12Volt DC electrical connections must be fused on the battery side. Make sure your radio and all other
devices will be turned off while connection your system.
If you need to replace the power fuse, replace it only with a fuse identical to that supplied with the system. Using a fuse
of different type or rating may result in damage to this system which isn't covered by the warranty.
Tools and materials you need
Please note
Planning your system
Mounting your amplifier
Warning
