General Information - Comunello Mowin R-control Bedienungsanleitung

1. GENERAL INFORMATION

Please read carefully and follow the instructions detailed in this manual. Keep the manual for use and future
maintenance. Pay attention to the configuration of the DIP-switches, to the data concerning the performance
(see "Technical Data").
2. TABLE OF TECHNICAL DATA AND MARK
The CE mark certifies that the trasmitter conforms to the essential health and safety requirements laid down
by European product directives. The CE mark can be identified by the relevant adhesive label applied to the
outside of the product, on which are shown some of the data shown in the following table:
Power Supply
Frequency
Channels
Range in open field
Max . absorption
Dimensions
Weight
R1-CONTROL
MX00 AT 01N 0G 00
2 x Lithium 3V (CR2032 230mAh)
434,15 MHz
1
300 mt
< 25mA
120x52x19 mm
40g
R6-CONTROL
MX00 AT 02N 0G 00
2 x Lithium 3V (CR2032 230mAh)
434,15 MHz
6
300 mt
< 25mA
120x52x19 mm
40g
Italian Movements
11
