Problem
Device does
not work
No reaction from
the laser when in
DMX operation
No reaction from
the laser when in
Music control
The projection
of the laser effect
is blurred
Repairs other than those just described should only be performed
by an authorised electrician.

Technical data

Operating voltage
Power consumption
Laser output
Wavelength
Laser class
Fuse
Control system
Control channels
Operating temperature
Dimensions (without bracket)
Mass
32
Solution
• Is the device switched on?
• Is the mains plug inserted into the mains socket?
• Is the low power mains connector plugged into the mains
connection?
• Is the fuse of the device defective?
• Check the mains socket. Does it have a proper supply of
power?
• Are the DIP switches on the device correctly set?
• Is the cover in front of the laser opening (1) open?
• Are the DMX cables plugged in?
• Are the DIP switches correctly set?
• Try to increase the sensitivity of the use music control by
setting the controller to LEVEL
(3) or turning up the music volume.
• Are the DIP switches on the device correctly set?
• Clean the deflector mirrors.
230 V~/50 Hz
50W
<5mW
532 nm
3R
Glass tube fuse 250V/2A (5x20mm)
DMX-512
1
18–25°C
220 x 212 x 105mm
4kg
