Pin/contact
26
27*
28*
29
30*
31*
32
33*
34*
35
36
37
38
39
40
Cheetah 4LP FC Installation Guide, Rev. B
Signal name
Ground
+Port B_in
–Port B_in
Ground
+Port A_out
–Port A_out
Ground
+Port B_out
–Port B_out
Ground
SEL_2
SEL_1
SEL_0
Reserved NC
5 Volts charge
Signal type
Diff. PECL input pair
Diff. PECL output pair
Diff. PECL output pair
TTL input
TTL input
TTL input
