BARRACUDA 4 Family
○
○
○
○
○
○
○
○
○
○
○
○
ST15150N/ND/DC
○
○
○
○
○
○
○
○
○
○
○
○
ST15150W/WD/WC
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
Installation Guide
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
Werbung
Inhaltsverzeichnis
Verwandte Anleitungen für Seagate ST15150ND
Inhaltszusammenfassung für Seagate ST15150ND
- Seite 1 ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ BARRACUDA 4 Family ○ ○...
-
Seite 2: Inhaltsverzeichnis
Installation des Laufwerkes und Anschluß der Kabel ........27 N/ND drives section ..........35 W/WD drives section ..........40 WC/DC drives section ..........46 © 1995 Seagate Technology, Inc. All rights reserved Publication Number: 83328870, Rev. E July 1995 Seagate ®... -
Seite 3: Preface
Ad- ditional information is available in the Barracuda 4 Product Manual (part number 83328880). Contact your Seagate sales representative if you need to order this publication. Electrostatic discharge protection Caution. Removal of circuit boards by personnel not performing depot repair will damage com- ponents and may void the warranty. -
Seite 4: Important Safety Information And Precautions
• Ground yourself to the drive whenever the drive electronics are or will be exposed. Connect yourself to ground with a wrist strap (Seagate part number 12263496). Connection may be made to any grounded metal assembly. As a general rule, remember that you and the drive electronics must all be grounded to avoid potentially damaging static discharges. - Seite 5 Barracuda 4 Installation Guide, Rev. E The procedures in this manual and labels on the unit contain warnings and cautions that must be carefully read and followed to minimize or eliminate the risk of personal injury. The warnings point out conditions or practices that may endanger you or others.
- Seite 6 Barracuda 4 Installation Guide, Rev. E • Wear safety shoes when removing or replacing heavy parts. • Ensure that the internal temperature of the rack or cabinet does not exceed the limits defined for the drive when the drive is mounted in an equipment rack or cabinet.
-
Seite 7: Wichtige Sicherheitshinweise
Barracuda 4 Installation Guide, Rev. E Seagate takes all reasonable steps to ensure that its products are certifiable to currently accepted stan- dards. Typical applications of these disc drives include customer packaging and subsystem design. Safety agencies conditionally certify component assemblies, such as the Barracuda disc drive, based on their final acceptability in the end-use product. - Seite 8 Barracuda 4 Installation Guide, Rev. E Reparaturverfahren, um den sicheren, zuverlässigen Betrieb dieser Einheit zu gewährleisten. Reparaturen dürfen nur von qualifiziertem Fachpersonal vorgenommen werden. Wir empfehlen die Verfahren in diesem Handbuch als effektive Methoden zur Wartung und Reparatur der Einheit. Einige Verfahren erfordern Spezialwerkzeuge;...
- Seite 9 Barracuda 4 Installation Guide, Rev. E verzichtet. Falls Sie ein hier nicht beschriebenes Verfahren oder Werkzeug verwenden, stellen Sie zuerst sicher, daß das gewählte Verfahren weder Ihre persönliche Sicherheit noch die Leistung der Einheit gefährdet. Beachten Sie in jedem Fall die folgenden Warn-und Vorsichtshinweise: •...
- Seite 10 Barracuda 4 Installation Guide, Rev. E oberen Stapelbereich, da dort die Temperatur gewöhnlich am höchsten ist. • Befolgen Sie die oben unter “Electrostatic Discharge Protection” angegebenen Sicherheitsmaßnahmen. • Nehmen keine Platinen Laufwerkgehäuse. Wenn eine Platine defekt ist, muß das gesamte Laufwerk zur Reparatur eingeschickt werden.
- Seite 11 Barracuda 4 Installation Guide, Rev. E Seagate ist ständig bemüht, die Zulassungsfähigkeit von Seagate-Produkten im Rahmen der gegenwärtig geltenden Standards zu gewährleisten. Zu den typischen Anwendungen dieser Festplattenwerke zählen Systemeinbau durch den Kunden und die Konstruktion von Untersystemen. Sicherheitsbehörden gewähren eine bedingte Zulassung für Komponenten wie das Barracuda-Festplattenlaufwerk vorbehaltlich der endgültigen Zulassung im Endprodukt.
-
Seite 12: Technical Support Services
Please contact your dealer for technical support and installation troubleshooting. Product technical support is available for all Seagate products by calling the SeaFAX™, SeaFONE™, SeaTDD™, or SeaBOARD™ services. These are toll calls if you dial from outside of the number’s local dialing area. - Seite 13 Technical support specialists are available 8:00 . to 5:00 . PST, Monday through Friday. Recorded tech- nical information for selected Seagate products is pro- vided while you are on hold. Recordings are accessible 24 hours a day, 7 days a week. SeaTDD: (408) 438-5382...
- Seite 14 Barracuda 4 Installation Guide, Rev. E Telephone Location number USA, Mexico, Latin America (408) 438-8771 England 44-62-847-8011 Germany 49-89-140-9331 Singapore 65-292-6973 Australia 61-2-756-2359 Canada (416) 856-5581 France 33-1-40-67-1034 Korea 82-2-556-7294...
-
Seite 15: General Description
Barracuda 4 Installation Guide, Rev. E General description Barracuda 4 disc drives are high-speed data storage devices. There are several models of this disc drive (see Figure 1, 2, or 3). Specifications and power require- ments for the drives are listed following the figures. The drive is a component for installation in an enclosure designed for the drive. - Seite 16 Barracuda 4 Installation Guide, Rev. E SCSI I/O Connector Pin 1 DC Power Connector Figure 2. Barracuda 4 disc drive (W/WD) Figure 3. Barracuda 4 disc drive (WC/DC)
- Seite 17 Barracuda 4 Installation Guide, Rev. E Characteristics of ST15150 drives N/ND W/WD/WC/DC SCSI-2 Interface Fast Fast & Wide Capacity Unformatted 5,062 Mbytes 5,062 Mbytes Formatted 4,294 Mbytes 4,294 Mbytes Recording Cylinders (user accessible) 3,711 3,711 Read/Write heads Servo heads Avg bytes/track 64,160 64,160 Modulation...
- Seite 18 Barracuda 4 Installation Guide, Rev. E DC power requirements N/W/WC ND/WD/DC + + + + + 5V + + + + + 12V + + + + + 5V + + + + + 12V ± ± ± ± ± 5% ±...
- Seite 19 Barracuda 4 Installation Guide, Rev. E Measured with average reading DC ammeter. Instanta- neous +12V current peaks will exceed these values. A –10% tolerance is permissible during initial start of spindle and must return to ±5% before 7,200 RPM is reached.
- Seite 20 Barracuda 4 Installation Guide, Rev. E continued from previous page Where power is provided to multiple drives from a com- mon supply, careful consideration for individual drive power requirements should be noted. Where multiple units are powered on simultaneously, the peak starting current must be available to each device.
-
Seite 21: Initial Setup Information
Barracuda 4 Installation Guide, Rev. E Initial setup information The general information beginning on this page applies to all of the Barracuda 4 models. After reading the general information topics, refer to the appropriate drive-specific section listed below for additional infor- mation about configuring and installing your particular model. - Seite 22 Barracuda 4 Installation Guide, Rev. E SCSI ID jumpers Each device on the SCSI chain must have a unique SCSI ID. The host system’s SCSI controller usually uses the highest-numbered ID available; therefore the lower-numbered SCSI IDs are normally used for other SCSI devices such as this Barracuda disc drive.
- Seite 23 Barracuda 4 Installation Guide, Rev. E Drive termination If you are installing the drive in a system that has other SCSI devices installed, terminate only the end devices on the SCSI chain. A SCSI “device” is any disc drive, scanner, tape backup unit, or other piece of hardware connected to your system using the SCSI bus.
- Seite 24 Barracuda 4 Installation Guide, Rev. E Terminator power You usually will not need to change this option and can normally leave the drive configured as it was shipped from the factory. For information about how to change the terminator power option on your drive, refer to the appropriate drive-specific section.
- Seite 25 Barracuda 4 Installation Guide, Rev. E system requirements; however, in most cases, you will not need to change any of these jumpers for normal drive operation. Providing adequate cooling The enclosure design must ensure adequate cooling for the drive. The maximum ambient temperature is 50 The drive’s product manual (83328880) describes how to evaluate the air-flow design.
-
Seite 26: Kühlung Des Systems
Barracuda 4 Installation Guide, Rev. E Kühlung des Systems Die Gehäusekonstruktion muß eine ausreichende Kühlung des Laufwerkes gewährleisten. Die Umgebungstemperatur darf maximal 50 C betragen. Die Produkthandbuch Barracuda 4 (Dokument 83328880) enthalten Anweisungen zur Beurteilung der Luftstromkonstruktion. Die Beurteilung muß sicherstellen, daß... - Seite 27 Barracuda 4 Installation Guide, Rev. E Above unit Über der Einheit Note. Air flows in the direction shown (back to front) or in reverse direction (front to back) Under unit Hinweis. Luftstrom in der angezeigten Richtung Unter der Einheit (von vorne nach hinten) oder in umgekehrter Richtung (von hinten nach vorne) Above unit Über der Einheit...
- Seite 28 Barracuda 4 Installation Guide, Rev. E Mounting the drive and connecting cables Note. This mounting procedure does not apply to WC or DC model drives. To mount a WC or DC drive, plug the drive into the system's single connector attachment (SCA) position on the system's back panel.
-
Seite 29: Installation Des Laufwerkes
Barracuda 4 Installation Guide, Rev. E Installation des Laufwerkes und Anschluß der Kabel Beachten Sie beim Handhaben und Anfassen der A n s c h l u ß s t i f t e u n d K o m p o n e n t e n d i e Vorsichtsmaßnahmen zur Verhinderung statischer Aufladung. - Seite 30 Barracuda 4 Installation Guide, Rev. E Notes: Mounting holes two on each side, 6-32 UNC. Max screw length into side of drive is 0.15 in. (3.81 mm). Mounting holes four on bottom, 6-32 UNC. Max screw length into bottom of drive is 0.15 in.
- Seite 31 Barracuda 4 Installation Guide, Rev. E .050 minimum clearance Notes: Mounting holes two on each side, 6-32 UNC. Max screw length into side of drive is 0.15 in. (3.81 mm). Mounting holes four on bottom, 6-32 UNC. Max screw length into bottom of drive is 0.15 in.
- Seite 32 Barracuda 4 Installation Guide, Rev. E 0.050" minimum clearance Notes: Mounting holes two on each side, 6-32 UNC. Max screw length into side of drive is 0.15 in. (3.81 mm). Mounting holes four on bottom, 6-32 UNC. Max screw length into bottom of drive is 0.15 in.
- Seite 33 Barracuda 4 Installation Guide, Rev. E 2. Verify that all connections between the drive and the host system are correctly installed. 2. Prüfen Sie, ob alle Verbindungen zwischen dem Laufwerk und dem Host-System korrekt hergestellt sind. 3. Verify that you have correctly installed SCSI ID jump- ers (see Figure 10, 15 or 21).
- Seite 34 Barracuda 4 Installation Guide, Rev. E darf nicht gedehnt oder gedrückt werden und es darf den Luftstrom zur Kühlung des Systems nicht behindern. Das Laufwerk wird über einen 4-poligen, neben dem SCSI-Anschluß befestigten Steckverbinder mit Gleichstrom versorgt. Der Ausgang eines Netzteils muß...
- Seite 35 Barracuda 4 Installation Guide, Rev. E mounted the drive is connected directly to the HDA and PCB without electrically isolating shock mounts. Maximizing the conductive contact area between HDA ground and system ground may reduce radiated emissions. If you do not want the system chassis to be connected to the HDA/PCB ground, you must provide a nonconductive (electrically isolating) method of mounting the drive in the host system.
- Seite 36 Barracuda 4 Installation Guide, Rev. E das Laufwerk auf nichtleitende Weise (galvanisch isoliert) im Host-System einbauen. Die daraus u.U. resultierende verstärkte elektromagnetische Strahlung fällt in den Zuständigkeitsbereich des Systemdesigners. 5. Replace the host system’s cover. 5. Setzen Sie das Gehäuseoberteil des Host-Systems wieder auf.
-
Seite 37: N/Nd Drives Section
Barracuda 4 Installation Guide, Rev. E Setting the SCSI ID jumpers Use the J4 connector to set the SCSI ID (Figure 10). To change the SCSI ID, install jumpers on the appropriate pins as shown in the illustration. SCSI Connector DC Power Connector Pin 1... - Seite 38 IC termina- tors and thereby remove internal termination from the drive. The ST15150ND drive does not have internal termina- tors or any way of adding internal termination. You must provide external active termination (ANSI SCSI-2 Alter- native 2) to the drive when termination is required.
- Seite 39 The ST15150ND drive should be configured with a jumper connecting J01 pins 1 and 3 (and no jumper on J01 pins 2 and 4) as illustrated in Figure 12.
- Seite 40 Barracuda 4 Installation Guide, Rev. E Synchronizing spindles Use pins 1 and 2 on the J4 connector to attach the spindle sync cable. See Figure 13. SCSI Connector DC Power Connector Pin 1 Pin 2 Spindle Sync Cable Connector (SSC). These pins are used to connect a spindle sync cable.
- Seite 41 Barracuda 4 Installation Guide, Rev. E Other applicable jumper options Several other jumper options are available as illustrated. SCSI Connector DC Power Connector Pin 1 Reserved (RES) Reserved for future use. Parity Check option (PAR) Enable parity check of SCSI bus data (default). Disable parity check.
-
Seite 42: W/Wd Drives Section
Barracuda 4 Installation Guide, Rev. E Setting the SCSI ID jumpers Use the J5 connector to set the SCSI ID (Figure 15). To change the SCSI ID, install jumpers on the appropriate pins as shown in the illustration. SCSI I/O DC Power Connector Pin 1... - Seite 43 Barracuda 4 Installation Guide, Rev. E Terminating the drive To terminate the ST15150W drive, enable the perma- nently mounted IC active terminators by installing an Enable Drive Terminator jumper on J4 pins 11 and 12 as shown in Figure 16. If you install one of these models and it is not on the end of the SCSI bus, remove the jumper to disable the permanently mounted IC termina- tors and thereby remove internal termination from the...
- Seite 44 Barracuda 4 Installation Guide, Rev. E Terminator power There are four possible terminator power configurations for the ST15150W drive (see Figure 17). You will not normally need to change this option and can leave the drive configured as it was shipped from the factory. The ST15150WD drive should be configured with a jumper connecting J01 pins 1 and 3 (and no jumper on J01 pins 2 and 4) as illustrated in Figure 17.
- Seite 45 Barracuda 4 Installation Guide, Rev. E Synchronizing spindles Use pins 11 and 12 on the J5 connector to attach the spindle sync cable. See Figure 18. SCSI I/O DC Power Connector Pin 1 Connector Spindle Sync Cable Connector (SSC) These pins are used to connect a spindle sync cable.
- Seite 46 Barracuda 4 Installation Guide, Rev. E Other applicable jumper options Other option jumpers are available as illustrated in Figures 19 and 20. Pin 1 Power Connector Write Protect option (WP) Write Protect = On (disables writing). Write Protect = Off (enables writing –...
- Seite 47 Barracuda 4 Installation Guide, Rev. E Pin 1 Parity Check option (PAR) Enable parity check of SCSI bus data (default). Disable parity check. Motor Start option (MTR) Enable motor start. The drive waits for the Start Unit command from the host before starting the spindle motor.
-
Seite 48: Wc/Dc Drives Section
Barracuda 4 Installation Guide, Rev. E Setting the SCSI ID jumpers The SCSI ID for WC and DC drives is normally set over the SCSI bus by the host system using connector contacts 39 (ID0), 40 (ID2), 79 (ID1), and 80 (ID3). Systems designers may, optionally, install a remote operator panel connection to set the SCSI ID. - Seite 49 Barracuda 4 Installation Guide, Rev. E Connecting remote LEDs Remote LED connections are provided on the J4 con- nector (see Figure 21). You can connect 2-pin remote LEDs using these connections. Attach the (-) lead to the appropriate pin and then attach the (+) lead to the pin labelled +5V.
- Seite 50 Barracuda 4 Installation Guide, Rev. E Pin 1 Pin 1 SCSI ID0 Fault LED pin (–) SCSI ID1 Vendor Unique SCSI ID2 Spindle Sync SCSI ID3 Drive Activity LED (–) Ground Write Protect Parity Enable Reserved Figure 21. Jumper options...
- Seite 51 Barracuda 4 Installation Guide, Rev. E...
-
Seite 52: Publication Number: 83328870, Rev. E
Barracuda 4 Installation Guide, Rev. E Seagate Technology, Inc. 920 Disc Drive, Scotts Valley, CA 95066-4544, USA Publication Number: 83328870, Rev. E, Printed in USA...
