AV-in1/AV-in2 Controls

AV-in1
AV-In1 is used for playback of audio/video from an external device connected to the unit through a
3.5mm jack located on the font panel.
AV-in2
AV-In2 is used for playback of audio/video from an external device connected
through RCA connectors located on the back of the unit.
You can connect an external audio/video device to the unit.
1. Connect the external device with an appropriate AV cable.
2. Touch the upper left corner to display the main menu.
3. Touch [Aux 1] / [Aux 2] to access external device.
note: Audio/Video device must be connected to the unit using an audio/video adapter
cable that is available separately.
note: Video will only play when the vehicle parking brake is engaged. the parking brake
must be connected for this feature to operate.
Figure 30. Connecting External Devices
82
Left Audio
1
Right Audio
2
Ground
3
Video
4
3.5 mm A/V Cable(not included)
