eQuAliZer Control Menu
Adjusting equalizer Controls
The Equalizer adjustment screen allows the user to easily adjust the audio system to meet the
acoustical characteristics of the vehicle depending on vehicle type and cabin dimensions. for
example: proper setting of the audio controls can improve the speakers frequency response.
The Balance/Fade levels and Loudness ON/OFF option of a selected audio/video source (Disc,
Radio, USB, AV-IN1, or AV-IN2) is also adjusted through the Equalizer adjustment screen.
equalizer (eQ)
Touch the Equalizer (EQ /
Techno / Rock / Classic / Jazz / Optimal or User)
note: the equalizer will automatically change to "user" when individual audio functions
are adjusted.
The programmable equalizer allows you to adjust the bass, mid and treble range both in terms of
intensity as well as in terms of frequency and the Q value (filter bandwidth).
The values for this are as follows:
For the bass range:
For the mid-range frequencies:
For the treble range:
) icon to view and select a desired acoustical preset level ( Pop /
Figure 18. Equalizer (EQ) Screen
Frequency:
Q value:
Frequency:
Q value:
Frequency:
74
60 / 80 / 100 / 200 kHz
1 / 1.25 / 1.5 / 2
0.5 / 1 / 1.5 / 2.5 kHz
0.5 / 0.75 / 1.0 / 1.25
10 / 12.5 / 15 / 17.5 kHz
