CTRL CHANGE MAPPINGS
+---------+---------------------------------------+-----+-----+
| Hex Dec | Ctrl parameter
+----+----+---------------------------------------+-----+-----+
|$07
07 | Track level
|$08
08 | Track balance
|
...
| ...
|$10
16 | Playback param #1
|$11
17 | Playback param #2
|$12
18 | Playback param #3
|$13
19 | Playback param #4
|$14
20 | Playback param #5
|$15
21 | Playback param #6
|$16
22 | Amp param #1 (Attack)
|$17
23 | Amp param #2 (Hold)
|$18
24 | Amp param #3 (Release)
|$19
25 | Amp param #4 (Volume)
|$1A
26 | Amp param #5 (Balance)
|$1B
27 | Amp param #6 (N/A)
|$1C
28 | LFO param #1 (Speed 1)
|$1D
29 | LFO param #2 (Speed 2)
|$1E
30 | LFO param #3 (Speed 3)
|$1F
31 | LFO param #4 (Depth 1)
|$20
32 | LFO param #5 (Depth 2)
|$21
33 | LFO param #6 (Depth 3)
|$22
34 | Effect 1 param #1
|$23
35 | Effect 1 param #2
|$24
36 | Effect 1 param #3
|$25
37 | Effect 1 param #4
|$26
38 | Effect 1 param #5
|$27
39 | Effect 1 param #6
|$28
40 | Effect 2 param #1
|$29
41 | Effect 2 param #2
|$2A
42 | Effect 2 param #3
|$2B
43 | Effect 2 param #4
|$2C
44 | Effect 2 param #5
|$2D
45 | Effect 2 param #6
|$2E
46 | Track level
|$2F
47 | Cue level
|$30
48 | Crossfader
|$31
49 | Track Mute (0=Unmuted, [1-127]=Muted
|$32
50 | Track Solo (0=No solo, [1-127]=Soloed |
|$33
51 | Track Cue
(0=Not Cued, [1-127]=Cued
|$34
52 | Track Arm (0=Trk disarm, [1-127]=Arm
|$35
53 | Recrdr Arm (0=Rec disarm, [1-127]=Arm |
|$36
54 | All Arm (0=All disarm, [1-127]=Arm
|$37
55 | Scene A Select
|$38
56 | Scene B Select
|$39
57 | Pickup SRC AB level
|$3A
58 | Pickup SRC CD level
|$3B
59 | Note on
(0=C-1, 127=G9)
|$3C
60 | Note off (0=C-1, 127=G9)
|$3D
61 | Send request, 0 = all audio CC
|
...
| ...
|$70
112 | MIDI Trk 1 Mute (0=Unmute,[1-127]=Mute|
|$71
113 | MIDI Trk 2 Mute (0=Unmute,[1-127]=Mute|
|$72
114 | MIDI Trk 3 Mute (0=Unmute,[1-127]=Mute|
|$73
115 | MIDI Trk 4 Mute (0=Unmute,[1-127]=Mute|
|$74
116 | MIDI Trk 5 Mute (0=Unmute,[1-127]=Mute|
|$75
117 | MIDI Trk 6 Mute (0=Unmute,[1-127]=Mute|
|$76
118 | MIDI Trk 7 Mute (0=Unmute,[1-127]=Mute|
|$77
119 | MIDI Trk 8 Mute (0=Unmute,[1-127]=Mute|
|$78
120 | MIDI Trk 1 Solo (0=Unsolo,[1-127]=Solo|
|$79
121 | MIDI Trk 2 Solo (0=Unsolo,[1-127]=Solo|
|$7A
122 | MIDI Trk 3 Solo (0=Unsolo,[1-127]=Solo|
|$7B
123 | MIDI Trk 4 Solo (0=Unsolo,[1-127]=Solo|
|$7C
124 | MIDI Trk 5 Solo (0=Unsolo,[1-127]=Solo|
|$7D
125 | MIDI Trk 6 Solo (0=Unsolo,[1-127]=Solo|
|$7E
126 | MIDI Trk 7 Solo (0=Unsolo,[1-127]=Solo|
|$7F
127 | MIDI Trk 8 Solo (0=Unsolo,[1-127]=Solo|
+---------+---------------------------------------+-----+-----+
C-2
| Trn | Rec |
|
|
X
|
|
|
X
|
|
|
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
X
|
Anhang C: MIDI-CCs
MIDI MODE CTRL CHANGE MAPPINGS
While in MIDI mode and CC DIRECT CONNECT is deactivated, the
auto channel and the MIDI tracks respond to the following CC
messages. The active MIDI track will however always respond as
if CC DIRECT CONNECT is set to ON.
+---------+---------------------------------------+-----+-----+
| Hex Dec | Ctrl parameter
+----+----+---------------------------------------+-----+-----+
|$10
16 | Playback param #1 (Note)
|$11
17 | Playback param #2 (Velocity)
|$12
18 | Playback param #3 (Length)
|$13
19 | Playback param #4 (Note 2)
|$14
20 | Playback param #5 (Note 3)
|$15
21 | Playback param #6 (Note 4)
|$16
22 | Arp param #1 (Transpose)
|$17
23 | Arp param #2 (Legato)
|$18
24 | Arp param #3 (Mode)
|$19
25 | Arp param #4 (Speed)
|$1A
26 | Arp param #5 (Octave Range)
|$1B
27 | Arp param #6 (Arp Note Length)
|$1C
28 | MIDI LFO param #1 (Speed 1)
|$1D
29 | MIDI LFO param #2 (Speed 2)
|$1E
30 | MIDI LFO param #3 (Speed 3)
|$1F
31 | MIDI LFO param #4 (Depth 1)
|$20
32 | MIDI LFO param #5 (Depth 2)
|$21
33 | MIDI LFO param #6 (Depth 3)
|$22
34 | Pitch bend
|$23
35 | Aftertouch
|$24
36 | CC #1 param
|$25
37 | CC #2 param
|$26
38 | CC #3 param
|$27
39 | CC #4 param
|$28
40 | CC #5 param
|$29
41 | CC #6 param
|$2A
42 | CC #7 param
|$2B
43 | CC #8 param
|$2C
44 | CC #9 param
|$2D
45 | CC #10 param
|$2E
46 | ...
|$2F
47 | ...
|$30
48 | ...
|$31
49 | MIDI Trk Mute (0=Unmuted [1-127]=Muted|
|$32
50 | MIDI Trk Solo (0=No solo [1-127]=Solo |
|
...
| ...
|$36
54 | All Arm (0=All disarm, [1-127]=Arm
|$37
55 | Scene A Select
|$38
56 | Scene B Select
|
...
| ...
|$70
112 | MIDI Trk 1 Mute (0=Unmute,[1-127]=Mute|
|$71
113 | MIDI Trk 2 Mute (0=Unmute,[1-127]=Mute|
|$72
114 | MIDI Trk 3 Mute (0=Unmute,[1-127]=Mute|
|$73
115 | MIDI Trk 4 Mute (0=Unmute,[1-127]=Mute|
|$74
116 | MIDI Trk 5 Mute (0=Unmute,[1-127]=Mute|
|$75
117 | MIDI Trk 6 Mute (0=Unmute,[1-127]=Mute|
|$76
118 | MIDI Trk 7 Mute (0=Unmute,[1-127]=Mute|
|$77
119 | MIDI Trk 8 Mute (0=Unmute,[1-127]=Mute|
|$78
120 | MIDI Trk 1 Solo (0=Unsolo,[1-127]=Solo|
|$79
121 | MIDI Trk 2 Solo (0=Unsolo,[1-127]=Solo|
|$7A
122 | MIDI Trk 3 Solo (0=Unsolo,[1-127]=Solo|
|$7B
123 | MIDI Trk 4 Solo (0=Unsolo,[1-127]=Solo|
|$7C
124 | MIDI Trk 5 Solo (0=Unsolo,[1-127]=Solo|
|$7D
125 | MIDI Trk 6 Solo (0=Unsolo,[1-127]=Solo|
|$7E
126 | MIDI Trk 7 Solo (0=Unsolo,[1-127]=Solo|
|$7F
127 | MIDI Trk 8 Solo (0=Unsolo,[1-127]=Solo|
+---------+---------------------------------------+-----+-----+
| Trn | Rec |
|
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
X
|
X
|
|
|
X
|
|
|
X
|
|
|
X
|
|
X
|
|
X
|
|
|
|
|
|
X
|
|
|
X
|
|
|
X
|
|
|
|
|
X
|
|
X
|
|
X
|
|
X
|
|
X
|
|
X
|
|
X
|
|
X
|
|
X
|
|
X
|
|
X
|
|
X
|
|
X
|
|
X
|
|
X
|
|
X
|
