this type of use.
When the microphone is to be used outdoors, a wind shield
should be fitted. The WS 740 is designed to stop low-frequency
interference caused by turbulent wind and can be fitted on the
microphone basket.

Adjusting the polar pattern

The relevant polar pattern is adjusted by a knurled knob
on the front side of the microphone.
omnidirectional
hypercardioid
The "R" position designates "Remote Control" which, however,
is not available and might be used for future options.

Adjusting the pre-attenuation

Without pre-attenuation (0 dB) the microphone has a
maximum SPL of 127 dB. At higher SPL pre-attenuation of
10 dB or 20 dB can be adjusted with the knurled knob at the
rear of the microphone (indicating -10 dB or -20 dB).
Pre-attenuation
OFF
wide cardioid
figure-eight
Pre-attenuation
ON
cardioid
Pre-attenuation
ON
