Hotronix® Dual Air Fusion™

Ersatzteilliste

Item # Part Name
1 Control Housing
2 Switch On/Off Lighted
3 Quick Release Button
4 Switch, Print, Canada
5 Touch Screen Controller
6 Control Housing Overlay
7 Power Cord
8 Print Valve
9 Swing Valve
10 Mini Regulator
11 E/P Regulator
12 Miain Swing Spindle
13 Flange Bushing 1"
14 C-Clip
15 Air Cylinder
16 Spanner Nut
17 Upper Casting
18 Press Mount
19 Silicone Pad 16x20, Blue
20 Lower Platen, 16 x20
21 Quick Release Pin
22 Adapter Plate
23 Guide Tube
24 Heat Platen Cover
25 Heat Platen 16x20
26 Thermostat
27 Silicone Dampener
28 Rodless Cylinder
29 Right Side Tin (Part of Tin Assembly)
30 Circuit Breaker, 10 amp
31 IEC Inlet
32 Foot Pedal Assembly
33 Access Plate (Part of Tin Assembly)
34 Self Leveling Stem Caster/ (Part of Leg Assembly)
35 End Cap (Part of Leg Assembly)
36 Leg Assembly
37 Rubber Foot (Part of Leg Assembly)
38 Base Casting
39 Air Filter
40 Clamp Assembly
41 Base Plate
42 Magnet, Slotted
43 Drive Angle
44 Hard Stop
45 Carriage Plate
46 Blocks (Part of Rails # 47)
47 Rails
48 Front Tin (Part of Tin Assembly)
49 Keeper
50 Probe
51 Back Tin (Part of Tin Assembly)
52 Cable Carrier
53 Left Side Tin (Part of Tin Assembly)
54 End Plate Stop
55 Bellow
56 Laser Mount Bracket (Part of Laser Light Assembly)
57 Diode (Part of Laser Light Assembly)
58 Laser Holder (Part of Laser Light Assembly)
59 Laser Swivel Ball Plate (Part of Laser Light Assembly)
60 Laser Swivel Ball (Part of Laser Light Assembly)
Part #
1-2197-1
1-2087
1-2270
1-2319
1-2266
1-2198
2-1013-1
1-2298
1-2299
1-2297
1-2293
2-1670
1-2282
1-2286
1-2264
2-1006-95
3-1341
1-2347
1-2136
2-1029-HD
1-2215
3-1336
1-2290
1-2263
2-1002-3-HW
1-2076
No part #
1-2338
1-2340
1-1331-2
1-1759
1-2305
1-2340
1-2345
1-2345
1-2345
1-2345
4-1176
1-1215
1-2332-1
No part #
1-1219
1-2341
1-2343
1-2344
1-2336
1-2336
1-2340
1-2342
1-1272-1
1-2340
1-2337
1-2340
No part #
1-2335
No part #
No part #
No part #
No part #
No part #
Qty
.
1
1
1
2 each
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2 each
2 each
2
2
1
1
1
1 each
1
1
1
2
1
2
1
4 each
2
1
4
1
1
2
1
1
2 each
2 each
1
2 each
2 each
1
2 each
1
1
1
1
2 each
1
1
4 each
4 each
4 each
19
4 each
