USB Connection
The Audiolink Light communicates with your computer through a USB port. It is also powered by
the USB connection. Because of this, we recommend that you plug the Audiolink Light into one of
the built-in USB ports on your computer, not through a keyboard connection or USB hub.
The installation under Windows will then take place automatically, a few seconds after connecting
to your computer-system it will find a "USB Audio Codec" or "USB Audio Device", which can be
used in each application and adjusted in the system control. Using the USB connection your
digitized audio data can now be transferred to your computer!
To connect your Audiolink Light, find the open jack of an unused USB port on your computer and
connect it to the Audiolink Light jack with the included USB cable.This computers USB jacks will
most often be located on a rear panel and will probably be marked with a USB symbol. In Windows
XP,Vista and Windows 7,8,10, the Audiolink Light is class-compliant, making driver installation
optional - to begin using the Audiolink Light, you may simply plug the unit into a USB port.
However, choosing to install the ASIO driver will allow the following added functionality:
Windows XP,Vista and Windows 7,8 and 10 - Device Control Panel and ASIO support with low-
latency drivers.
MIC and INSTRUMENT Inputs
Connect your Microphone at the XLR input or your electric guitar to the Instrument input. If you
use a Microphone, which needs phantom power you find the phantom power switch on the back
side of the Audiolink Light. You can adjust the input level of each channel of the Microphone with
the Input levelers beside the XLR input sockets.
LINE-Output (Stereo TRS Jacks)
Connect your amplifier to these outputs for monitor recordings or sounds from the computer.
HEADPHONE-Output (Stereo Jack 6,3 mm) (left side of the LINE OUT)
Connect your headphone to this output to monitor recordings or sounds from the computer.
Windows XP/VISTA/Win 7 /8/10ASIO driver
On our website
www.miditech.de
you will find an ASIO driver for the Audiolink Light, after
download just execute the setup.exe and follow the instructions. After the installation you can find
in each ASIO compatible recording software the Audiolink Light ASIO control panel. There you
can adjust the recording speed.
We recommend that you download the Audiolink Light ASIO driver from our homepage
www.miditech.de. The ASIO driver makes it possible to use monitoring- and full duplex- modes.
Additionally, the latency time of the audio signal will be substantially reduced.
Note: Shorter latency time will occupy more CPU source, 4~11msec for average PC. If you hear
some "POP...", please drag it higher to 8~20msec.
Further information on extensions, updates and other products from Miditech please check out our
homepage http://www.miditech.de!
Changes of the technical data and the design are possible
No liability is assumed for misprints
